| Prod Model: |
BU |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity: |
9000-12000 BTU |
| Usage: |
Room |
| Indoor Machine Noise: |
24-35dB |
| Certification: |
CE |
| China Energy Efficiency Standard: |
Level 5 |
| Cooling/Heating: |
Cooling/Heating |
| Power Source: |
Electrical |
| Power Type: |
AC |
| Condition: |
New |
| Type: |
Split Type |
Product Description
Professional OEM Manufacturer For Air Conditioner, CE RoHS UL SAA SONCAP SASO cUL CSA ETL Certifications ISO9001 Passed
Air Conditioner Feature&Function
Powerful cooling
Energy saving and Durable
Cmpressor: Toshiba.
Capacity: 9000-24000BTU
Cooling only / cooling and heating
COP/EER: 3.6/3.45
Gas: R22, R410A
Power: 220-110V
Working condition: T1, T2, T3
Compressor: TOSIHBA,
Features and specifications:
1) Multi-angle air intake
2) with LED and VDF display.
3) Sleep mode
4) 24-hour timer
5) Independent dehumidifying function
6) Removable & Washable Panel, Color Panel
7) High Coefficient of Performance & Energy Efficiency Ratio
8) Auto recovery after power resumption
| No. | Model | 9000BTU-C | 9000BTU-C&H | 12000BTU-C | 12000BTU-C&H |
| 1 | Type | Cooling only | Heating Pump | Cooling only | Heating Pump |
| 2 | Control type | remote | remote | remote | remote |
| 3 | Power supply | 115V~/60Hz/1P | 115V~/60Hz/1P | 115V~/60Hz/1P | 115V~/60Hz/1P |
| 4 | Rated cooling capacity | Btu/h | 9000 | 9000 | 12000 | 12000 |
| 5 | Rated Heating capacity | Btu/h | N.A | 9500 | N.A | 12500 |
| 6 | SEER | Btu/W.h | 13.5 | 13.5 | 13.0 | 13.0 |
| 7 | HSPF Rating (Region IV) | Btu/W.h | N.A | 9.0 | N.A | 8.1 |
| 8 | HSPF Rating (Region V) | Btu/W.h | N.A | 8.0 | N.A | 7.0 |
| 9 | EER | Btu/W.h;W/W | 11.6/3.4 | 11.6/3.4 | 10.9/3.2 | 10.9/3.2 |
| 10 | COP | W/W | N.A | 3.6 | N.A | 3.6 |
| 11 | Rated current | Cooling | A | 7.3 | 7.3 | 9.5 | 9.5 |
| Heating | A | N.A | 7.4 | N.A | 9.0 |
| 12 | Rated input | Cooling | W | 800 | 800 | 1100 | 1100 |
| Heating | W | N.A | 810 | N.A | 1000 |
| 13 | Moisture removal | Liters/h | 0.8 | 0.8 | 1.0 | 1.0 |
| 14 | Indoor noise level at cooling | High | dB(A) | 40 | 40 | 42 | 42 |
| Med. | dB(A) | 38 | 38 | 40 | 40 |
| Low | dB(A) | 36 | 36 | 38 | 38 |
| 15 | Outdoor noise level | dB(A) | 50 | 50 | 52 | 52 |
| 16 | Connecting Pipe | Gas | Inches | 3/8'' | 3/8'' | 3/8'' | 3/8'' |
| Liquid | Inches | 1/4'' | 1/4'' | 1/4'' | 1/4'' |
| 17 | Connecting Wiring | Size x Core number | 3×1.5 | 3×1.5;2×0.75 | 3x2.5 | 3x2.5;2x0.75 |
| 18 | Suitable area | m 2 | | | | |
| 19 | Net dimensions (W x H x D) | Indoor | mm | 800×280×185 | 800×280×185 | 900×280×202 | 900×280×202 |
| Outdoor | mm | 760×552×256 | 760×552×256 | 760×552×256 | 760×552×256 |
| 20 | Net weight | Indoor | kg | 10 | 10 | 11 | 11 |
| Outdoor | kg | 32 | 33 | 33 | 34 |
| 21 | Packing dimensions (W x H x D) | Indoor | mm | 885×366×278 | 885×366×278 | 995×365×298 | 995×365×298 |
| Outdoor | mm | 863×598×376 | 863×598×376 | 863×598×376 | 863×598×376 |
| 22 | Gross weight | Indoor | kg | 13 | 13 | 14 | 14 |
| Outdoor | kg | 35 | 36 | 36 | 37 |
| 23 | Loading Capacity | 40’/40’HC | 245 | 245 | 220 | 220 |
| *** Indoor Unit *** | | |
| 1 | Motor Brand | | | | |
| 2 | Motor Model(Factory Code) | GGSDJ-04a | GGSDJ-04a | GGSDJ-04a | GGSDJ-04a |
| 3 | Motor Power Output | W | 12W | 12W | 12W | 12W |
| 4 | Motor Rotating Speed RPM | Cooling | RPM | 1300/1200/1100 | 1300/1200/1100 | 1270/1170/1000 | 1270/1170/1000 |
| heating | RPM | N.A | 1250/1150/1050 | N.A | 1250/1150/1000 |
| Dry | RPM | 1100 | 1100 | 1000 | 1000 |
| Sleep | RPM | 1050 | 1050 | 1000 | 1000 |
| 5 | Indoor fan type | | Cross Flow | Cross Flow | Cross Flow | Cross Flow |
| 6 | Indoor air circulation/Hi | m3/h | 550 | 550/550 | 730 | 730/800 |
| 7 | Length of Blower | mm | 710 | 710 | 710 | 710 |
| 8 | Diameter of Blower | mm | 94 | 94 | 94 | 94 |
| 9 | Pieces of Fan Blade of Blower | | | | | |
| 10 | Length of Evaporator | (mm) | 617 | 617 | 705 | 705 |
| 11 | Hight of Evaporator | (mm) | 315 | 315 | 315 | 315 |
| 12 | Width of Evaporator | (mm) | 25.4 | 25.4 | 25.4 | 25.4 |
| 13 | Rows/Pieces of Copper Tube | | 2/15 | 2/15 | 2/15 | 2/15 |
| 14 | Tube Type | | Triangular inner groove | Triangular inner groove | Triangular inner groove | Triangular inner groove |
| 15 | Tube Diameter OD mm | mm | 7 | 7 | 7 | 7 |
| 16 | Pieces of Fin Per Inch | | 18 | 18 | 18 | 18 |
| 17 | Fin type | | Slit Fin | Slit Fin | Slit Fin | Slit Fin |
| *** Outdoor Unit *** | | |
| 1 | Compressor Brand | | TOSHIBA | TOSHIBA | TOSHIBA | TOSHIBA |
| 2 | Compressor Model | | EA82X1C-1FZDU1 | EA82X1C-1FZDU1 | EA108X1C-1FZDU1 | EA108X1C-1FZDU1 |
| 3 | Motor Brand | | | | | |
| 4 | Motor Model | | GZSDJ-03a | GZSDJ-03a | GZSDJ-03a | GZSDJ-03a |
| 5 | Motor Power Output W | W | 31 | 31 | 31 | 31 |
| 7 | Motor Rotating Speed RPM | RPM | 860 | 860 | 860 | 860 |
| 8 | Outdoor fan type | | Propeller fan | Propeller fan | Propeller fan | Propeller fan |
| 9 | Diameter of Fan | mm | 408 | 408 | 408 | 408 |
| 10 | Pieces of Fan Blade | | 3 | 3 | 3 | 3 |
| 11 | Pieces of Fin Per Inch | | 17 | 17 | 17 | 17 |
| 12 | Fin Type | | Slit Fin | Slit Fin | Slit Fin | Slit Fin |
| 13 | Rows/Pieces of Copper Tube | | 2/24 | 2/24 | 2/24 | 2/24 |
| 14 | Tube Type | | Triangular inner groove | Triangular inner groove | Triangular inner groove | Triangular inner groove |
| 15 | Tube Diameter OD | mm | 7 | 7 | 7 | 7 |
| 16 | Length of Condensor | mm | 708 | 708 | 708 | 708 |
| 17 | Hight of Condensor | mm | 510 | 510 | 510 | 510 |
| 18 | Width of Condensor | mm | 25.4 | 25.4 | 25.4 | 25.4 |
| 19 | Controlling Refrigerant | | R410A | R410A | R410A | R410A |
NINGBO AKL-Histar Electric Co., Ltd was founded in 2004. Main products consist of various electric appliance, and more than 70 kinds in all. with complete specifications, novel models, products are extensively applied to home and commercial department. Our products export to the whole world. Europe, South & North America, Southeast Asia, Africa and Middle East. Our factory obtains reliance and praise from customers and societies with excellent quality and competitive price.
Our company has passed CE, RoHS. COC, SAA. SONCAP. UL. SASO Certificate. For purpose to control products' quality well, we develop a whole set of standard testing equipment by ourselves.
We always insist on the management aim of "quality first, customers supreme", strive for top grade products and offer first rate service. We sincerely welcome the old and new customers to visit our factory, negotiate business, cooperate extensively and achieve common prosperity.
