| Prod Model: |
UKK model |
| Markets: |
South America,Eastern Europe,Southeast Asia,Oceania,Western Europe |
| Size: |
800*235*185mm |
| Weight: |
40kg |
| Type: |
Inverter Air Conditioner |
| Usage: |
Room |
| Indoor Machine Noise: |
24-35dB |
| Certification: |
GS |
| China Energy Efficiency Standard: |
Level 1 |
| Cooling/Heating: |
Cooling/Heating |
| Power Source: |
Electrical |
| Power Type: |
DC |
| Condition: |
New |
| Capacity: |
9000-24000BTU |
Product Description
| Model | 9000btu | 12000btu | 18000btu | 24000btu |
| Rated Capacity | Cooling | W | 2600(1400-3100) | 3500(1500-3601) | 5200(2400-5800) | 7000(2600-7500) |
| Heating | W | 2700(1300-3000) | 3600(1150-3600) | 5300(2400-5800) | 7300(2350-8100) |
| Dehumidifying | Kg/h | 0.8 | 1 | 1.6 | 2.2 |
| Rated Power Consumption | Cooling | W | 640(240-1180) | 1100(190-1300) | 1700(350-2100) | 2000(320-3200) |
| Heating | W | 780(330-850) | 1008(280-1200) | 2100(500-2250) | 2540(460-3700) |
| Rated Running Current | Cooling | A | 3.7(1.3-5.2) | 6.2(1.0-6.9) | 8.5(2.0-9.5) | 109(1.6-13.5) |
| Heating | A | 3.6(2.2-3.9) | 4.8(1.5-5.8) | 10(2.5-11.5) | 11.2(2.4-16.5) |
| Electricheating power Power | W | / | / |
| / |
| Max. Input Power | W | 1500 | 1500 | 2250 | 3800 |
| Max. Input Current | A | 7 | 7 | 11.5 | 17 |
| EER Cooling | W/W | SEER5.3 | SEER5.7 | SEER5.60 | SEER5.65 |
| COP Heating | W/W | SCOP3.81 | SCOP3.81 | SCOP3.82 | SCOP3.80 |
| Power supply source | V/Ph/Hz | 220-240V~/50HZ | 220-240V~/50HZ | 220-240V~/50HZ | 220-240V~/50HZ |
| Refrigerant |
| R410A | R410A | R410A | R410A |
| Refrigerant Charged | g | 870 | 1000 | 1750 | 2100 |
| Max. Discharge Pressure | Mpa | 4.15 | 4.15 | 4.15 | 4.15 |
| Max. Suction Pressure | Mpa | 1.15 | 1.15 | 1.15 | 1.15 |
| Air Flow Volume | m3/h | 630 | 630 | 920 | 1200 |
| Noise level | dB(A) | 43 | 43 | 52/60 | 56 |
| Noise level | dB(A) | 53 | 53 | 60/65 | 61 |
| Indoor unit weight (Net ) | Kg | 10.5 | 10.5 | 12 | 19 |
| Outdoor unit weight (Net ) | Kg | 31 | 31 | 46 | 60 |
| Dimension | Packing Type |
| NO | NO | NO | NO |
| Net Dimension | mm | 760×540×260 | 760×540×260 | 800×690×300 | 902×795×332 |
Packing Dimension
(WidthxDepthxH) | mm | 880×600×370 | 880×600×370 | 940×750×420 | 1030×860×430 |
SCOP 3.8 European new energy standard Air Conditioner, with high efficiency and Eco-friendly.
