| Prod Model: |
CA-18 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Protection Function: |
DC, Overload, Overheat, Short Circuit Protection |
| Suitable For: |
Disco, Night Club, Pub, High Grade KTV |
| Dimensions: |
490W*455D*145h |
| Type: |
Professional Amplifier |
| Function: |
Post Amplifier |
| Tube Type: |
Transistor Amplifier |
| Element Number: |
Push-Pull Amplifier |
| Used For: |
Professional |
| Conductive Mode: |
AB |
| Usage: |
Club, Disco, Dancing Hall, Theater |
| Voltage: |
110V-135V, 135V-240V |
| Output Number: |
2 |
Product Description
Name: sound standard CA18 Power amplifier
Frequency Response:-20--20K+0/-0.3dBTHD+N:-<0.03%@8?1HzS/N Ratio>93dBSlew Ratio:-44V/uSDamping Factor>300Crosstalk>70dB@8?1KHzInut Impedance:20K?(Balance)/10K?(Upnbalance)Input Sensitivity0.775V/1.0/1.4VProtect:-Overheat short circuits, DC, limit and—soft start, Output relay-Zero Current Switch, Intellectual Clip limiter.Height:-3UCharacteristics:
Its exquisite design, competitive price with high-level performance attract a lot of customers.
Toshiba imported large power tube makes the voice soft and beautiful.
The tunnel type heat radiation structure, better heat dissipation effect. Using the high efficiency intelligent fan cooling system, to reduce the noise at the same time, but alos can guarantee the machine long time stability.
Suitable for disco, night club, PUB, high grade KTV.
About Us: Guangzhou Yunqiang Electronics Limited is a developing amplifier, speaker, stage lighting factory in Guangzhou, China. Based in the interenational and manufactures innovative, . High quality amplifier, speaker, STAGE LIGHTING DJ EQUIPMENT products for the professional CLUB PARTY and stage SHOW entertainment & leisure
Our purpose:
Quality first, Credit first, Customer first, First-rate service.
We insist in "honest business and high quality service" as our business ideal, with a powerful R&D team and a group of skilled workers in the factory as the strong backup and support, we always work on this ideal to serve all customers with good quality and reasonable price.
|
Model |
CA-10 |
CA-12 |
CA-16 |
CA-18 |
|
Power(8ohm) |
300W*2 |
400w*2 |
500W*2 |
700W*2 |
|
Power(4ohm) |
450W*2 |
650w*2 |
750W*2 |
1000W*2 |
|
Frequency Response |
20Hz-20kHz,(+0.1,-0.1dB) |
|
Signal to noise |
85dB |
86dB |
90dB |
94dB |
|
Input sensitivity |
0.4v |
0.6V |
0.65v |
0.7V |
|
THD |
≤0.05% |
|
Input Impendance |
20Kohm |
|
Supply power |
2400w |
3000w |
3400w |
4500W |
|
Exchange Insurance |
8A |
10A |
10A |
15A |
|
Net weight |
16.5KG |
17.8KG |
22.5KG |
23.5KG |
|
Size |
490W*455D*145H |
|
Package Size |
575W*560D*200H |
Guangzhou YunQiang Electronics Co., Ltd. is a professional audio manufacturer which has R& D, Production department, Marketing Dept., and Technical and service Dept.,
The main products include: Power Amplifier, Karaoke amplifier, Professional Speaker, Karaoke speaker, Sound Mixer, Audio processor and Conferencing systems.
Nowadays, in professional sound industry, more and more people are seeking for amplifiers with light weight, high power output, high sound quality and high stability.
To get good sound quality, we should have high quality components. And to ensure the stability, we must solve the problem of heat dissipation. Now, we have this amplifier FP14000, FP10000Q, FP-8000Q. Our FP14000, FP10000Q, FP-8000Q is Class TD switching amplifier fixed with NOVER (from UK) power capacitors, ON-Semi power transistors other high quality electronic spare parts. Professional circuit design and actual copper heat sink with better structure make fast heat dissipation possible. And fast heat dissipation contributes to high stability of the amplifier. Once you have our amplifiers at your hands, open the chassis, you will find artwork and detail difference. The swich power amplifier can be used to drive line array loudspeaker systems in touring, living show and other applications with high requirement on sound quality and stability.
Since the foundation of our enterprises, we have been concentrating on designing new products, doing research on new sound technology, training our staff, as well as improving our quality to products and management system. And now we have had a unique management experience, advanced production equipment, abundant design capability, and the large marketing network and after-sales service system.
Now we have passed newest CE, FCC, RoHS, SGS, CCC, ISO9001 on March, 2015.
