| Prod Model: |
45 GQ series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Condition: New: |
Type: Centrifuge, Lab Equipment |
| Model Number: Gq Series: |
Application: Liquid |
| 0.4 To 3.0 Kw: |
Power(W): 3.0kw |
| Product Type: Blood Cell Separator: |
Model Number: Gq Series |
| Weight: 120 To 600kg: |
Warranty: 18 Months |
| Material: SUS304/316L: |
Capacity: 1000L/H |
| Approval: ISO9000:9001 GMP: |
Speed: 8000 to 30000rpm |
| Operation: Manual Or PLC Control: |
Through Output: 50 to 2000 Liter Per Hour |
| Type: |
Separation Type |
Product Description
Product Description
Fuyi High-speed centrifuge separator are widely used in a variety of biological processes from cell harvesting and clarifying to separations of chemicals, food, blood and pharmaceuticals. High performance is consistently achieved in continuous, semi-continuous or batch operations.
Ruggedly build in a range of sizes, Fuyi centrifuge separator provide an efficient, cost-effective technology for research through production applications. Fuyi Centrifuges separator efficiently separate from one to several thousand liters of biological cultures and other mixtures. For extremely high solid concentrations, drum centrifuge can be supplied for high performance separations.
How They Work
Fuyi Centrifuge are characterized by their ability to process many times the volume of their tubular bowl. Fluid mixtures are fed into the bottom of the rapidly rotating separating chamber. Solid are retained, while components are expelled from the top of the chamber through a collection tray.
For Liquid-Liquid separation , two collection trays are used. The retained solid cake is dry and densely packed by the high G-forces of the Fuyi Centrifuge. Plastic bowl liner are available for models GF/GQ-105/125/150 to facilitate cell paste removal.
The optimum size centrifuge for a given application depends on the volume and properties of the process liquid. Typical process volumes specified for each centrifuge are approximate. Contact NBS for a no-obligation consultation.
Typical Applications
Harvesting biomass
Clarifying process liquids
Separating liquid products
Fractionation of human blood
Animal blood processing
Bioremediation
Process of granular, crystalline & fibrous suspensions
Separation of filterable & non-filterable sludge
Features & Benefits
Rapid separations
Consistent performance
Range of models facilitate scale-up
Simple to set up, use and clean for minimal down-time between separations
No replacement membranes or costly disposables
Small footprint saves space
Enclosed models available for ambient gas control
For mixtures with very high solid concentration, drum centrifuge can be supplied
Power 3-phase electric motors provide rapid acceleration and quieter operation.
Control panel attached with drum centrifuge can be applied to online fault check: Temp. Vibration, speed, current and also can achieve remoting control and monitoring.
Permanently-lubricated oversized head bearings maintain long service life
Model |
Bowl Speed(rpm) |
G-Force |
Bowl Capacity Nominal Liters |
Running Load(Watts) |
Dimensions, Overall (mm) |
Width |
Front-to-Back |
Height |
45 |
10.000 to 28.000 |
19.800 |
0.4 |
0.4 |
500 |
420 |
760 |
Notice:
GQ: separator for liquid-solid
GF: separator for liquid-liquid-solid
We promise every parts of the centrifuge is made by ourself except for the machine body molding, thus it keep the centrifuge quality we can control by ourself as well and keep the long-time running without problem .
From the spindle to the separator bowl , each technics have at least more than 30 step to finish a parts .
We made Standard but we beyond it .
Our company was established in June 2011, formerly known as Liaoyang Sunny Pharmaceutical Machinery Co., Ltd. Our company is now a technologically advanced and high-tech enterprise integrating R&D, production, and sales. Our company is a member of National separation machinery of Standardization Technical Committees, and also the Council Member of China General Machinery Industry Association. The director of our company is one of the first separation equipment researchers in China who obtained multiple National awards. "Tubular Separator", currently in effect, is the national standard and was drafted by our company. And in the same industry, our company is one of the first batches to pass ISO9001: 2000 quality system certification.
Our comprehensive performance has reached the advanced international level. Our company and branch office cover a total area of 60mu (1mu equals to 666.7m2) and a building area of 13, 000 square meters for equipment design and manufacturing, equipment inspection and test run.
With spare parts library and the material separation lab and the full equipped equipment, our company is one of the biggest manufacturers of separator equipment in domestic market. Our team is consisting of technology developers, PHD, postgraduates and undergraduates. We have close technical exchanges with Chinese Academy of Sciences, Zhejiang University and Tianjin University. We have won lots of national technical patents. Every year our company attends world-class meetings on separator machine and learns frontier technology.
Our equipment is widely used in pharmaceutical, chemical, food, beverage, blood products, material classification, biological diesel oil and other industries for the separation of solid and liquid or the separation of liquid and liquid. At present, there are thousands of equipment with all sizes have been used in lot of well known industries. As a domestic industry leader, we would like to provide our various products, excellence quality and perfect service to meet the market demand in the whole world, win the majority of users' trust and become the pioneer of the machinery manufacturing industry in the new century!
