| Prod Model: |
pcb-0095 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Layer No.: |
1-16 |
| Cooper Thickness: |
0.5 Oz-11oz (18 Um-385 Um) |
| Finished Board Thickness: |
0.2 mm-3.8mm'(8 Mil-150 Mil) |
| Certificate: |
RoHS, ISO9001:2008, SGS, UL Certificate |
| Laminate Materials: |
Fr-4,Fr-1,,Fr-2,Cem-1,Cem-3 |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
We are the Printed Circuit Boards(PCB) manufacturer with 15 years experience, specialized in single-sided, 2-layerd, multilayer and high density interconnector (HDI) PCB.
Certification: UL, ISO14001, ISO9001, SGS, TS16949Used for auto industry, high power led, electric toy, machinery, industrial lighting and so on. Our process capability| Description | Capability |
| PCB Surface Finishes | electrolytic nickel-gold,
HASL(Lead Free, ENIG (Electroless Nickel/Immersion Gold, Carbon Ink, Golden Fingers, OSP (Entek, Immersion Tin, Immersion Silver |
| PCB Board Max. Size | 1200mm×600mm |
| PCB Board Min. Size | 5mm×5 mm |
| Bow & Twist Tolerance | Single Side≤1.0%,Double Side≤0.7%, Muti-Layer≤0.5% |
| Min. Board Thickness & Tolerance | 0.2mm±0.08mm |
| Min. trace/spacing | Tin board:0.2mm±20%(8mil±0%) |
| gold board:0.075mm±20%(3mil±0%) |
| Copper to Board Edge Spacing | 0.5mm(20mil) |
| Hole to Trace Spacing | 0.3mm(12mil) |
| Min. Hole Diameter | 0.2mm±.076mm(8mil±3mil) |
| Min. Hole Clearance | 0.4mm±.076mm(16mil±3mil) |
| Copper Thickness on Hole Wall | 20-25um(0.79mil-1.0mil) |
| Hole Location Tolerance | ±0.076mm(l±3mil) |
| Min Diameter of Punching Hole | FR-4 board thickness≤1.0mm(40mil):1.0mm(40mil) |
| FR-4 board thickness 1.2-3.0mm(48-120mil):1.5mm(60mil) |
| Min. Punching Slot | FR-4 CEM-3 board thickness≤1. 0mm(40mil):0.8 mm×0.8 mm(32mil×32mil) |
| FR-4 board thickness1.2-3.0mm(48-120mil): 1.0 mm×1.0 mm(40mil×40mil) |
| Trace width variation | ±0.076mm(±3mil) |
| Outline Tolerance | Routing:±0.1mm (±4mil) ,Punching:±0.05mm (±2mil) |
| V-CUT Registration Tolerance±0.2mm (±8mil) |
| Type | Single-sided, double-sided, multi-layer |
| Major Material | FR-4, CEM-1,CEM-3, high frequency laminates, Aluminum, NiFe-based, copper base |
| Thickness | 0.2-3.5mm |
| Base Copper Thickness | 11um 35um 70um 105um |
| Max. aspect ratio(board thickness: hole size) | 8:1 |
| V-Cut Angle Tolerance | ±5° |
| V-Cut Board Thickness | 0.4mm -3.2mm(16mil -128mil) |
| Min SMT Pitch | 0.3mm(12mil) |
| Min. Component mark | 0.15mm(6mil) |
| Min. width of annular ring(finished) | 0.15mm(6mil)/side |
| Min pad opening | 0.076mm(3mil) |
| Min S/M Bridge | ±0.076mm(±3mil) |
| carbon ink board manufacturing capability:1.Impedance Control:20K±10% 2.Hardness:6H 3.bearable friction times :above 200000 times |
What we need: Please tell us the information as below:| Board for what product | Surface Finish |
| Number of Layers | Board Material |
| Copper Thickness(um) | Board Thickness(um) |
| Solder Mask Color | PCB Dimensions(mm) |
| Silk Screen Color | Min Finished Hole Size(mm) |
| Milling | Min Clearance(mm) |
| Min Track Width(mm) | Other special requirements |
Fast delivery:| Packaging | Vacuum Packing with desiccant,
Professional Export Carton. |
Delivery
time |
| Prototype | Mass production
(above 30m) |
| 2L | Quick turn:24h
Usual time:3-4days | 5-10days |
| 4L | Quick turn:48 hours;
Usual time:5-6days | 8-15days |
| 6L | Quick turn:72 hours;
Usual time:6-8days | 10-16days |
| 8L | Quick turn:72 hours;
Usual time:8-10days | 16-18days |
| 10L | Quick turn:96 hours;
Usual time:12-14days | 18-20days |
| `` | `` | `` |
Please send us your Gerber Files and PCB specifications; we will quote for you within 12 hours.
We always try our best! So we do, we conquer, and we get there!
Contact us!!
Dongguan HRSC PCB Co., Ltd is a professional printed circuit board¨ PCB© Manufacturer with 15 years experience, specializing in single-sided, double-sided, multilayer and high density interconnector PCB, owning 100, 00 m2 factory, with 320 employee. Monthly output is 35, 000 m2.
HRSC has advanced processing equipments and highly skilled workers. Our products widely apply in lighting, electronic game machine, auto industry, communication equipment, computer peripheral product, medical devices, etc. The quality of products is highly praised by the industry. In 2013, we have introduced more advanced overseas brand machines, and strived to become fist-class PCB manufacturer.
We have successively obtained certification of UL, ISO14001, TS16949, passed SGS test. And meets RoHS and REACH standards. Then we are improving the management of market development, engineering design, manufacturing, quality assurance, after-sales service, and have enjoyed the industry good reputation and customers' trust. Presently our company has deeply trusted and well received by Japanese well-known enterprises and sino-foreign joint venture companies. To keep pace with the high-techn industries, HRSC always uphold the tenet "integrity, practical, innovation", exerting the advantages of market, technology and talents, to provide our customers with quality products and efficient service.
