| Prod Model: |
LG-220 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Fan Asisted Cooling: |
9cuft |
| Function: |
Cold Storage & Freezing |
| Type: |
Display Cooler |
| Door Type: |
Swing Door |
| Door Number: |
Single Door |
| Defrost Type: |
Manual Defrost |
| Capacity: |
401-500L |
| Power Source: |
Electricity |
| Temperature Type: |
Single-temperature |
| Temperature Control: |
Mechanical Thermostat |
| Certification: |
ETL |
Product Description
Product Description
Brief info
Model No. : LG-220
Certificate: CB, CE, RoHS, SONCAP
Size: 220L
Type: Plug in
Electric Feature: 220V, 50/60Hz, 110V/60Hz
Gas: R134a / R600a
Climate category: N~ST
Application: 0~10ºC beverage, beer
Basic features:
1, fan direct cooling, skin type evaporator
2, Double layer glass door, front side is tempered.
3, with lock&key, with 4 casters
4, with automatic closing door
5, with automatic drain-water evaporating
6, with front hot air blowing to relieve fog
options:
digital thermostat
extra shelf
canopy sticker
2 side + canopy sticker
aluminum cover door frame
LED light
Model No | LG-220 | LG-280 | LG-360 | LG-380 |
| Size | Outer size(L×W×H)(mm) | 535X525X1770 | 575X606X1830 | 575X606X1980 | 575X606X1980 |
| Packing size(L×W×H)(mm) | 565x560x1815 | 630×624×1875 | 630×624×2003 | 630×624×2003 |
| Gross volume (L) | 220 | 280 | 360 | 380 |
| Net weight (KG) | 60 | 66 | 73 | 73 |
| Gross weight (KG) | 66 | 72 | 80 | 80 |
| Stucture | lightbox | YES |
| glass door | two layer glass front size tempered |
| cooling system | fan assisted cooling |
| compressor | Bottom mounted |
| Wheels / feet | 4 universal wheels, 2 with brake |
| Features | body Color | white (blue and red color are optional) |
| Outer finishing | PPGI (prepainted galvanized steel) |
| Inner finishing | Painted aluminum |
| Evaporator type | skin evaporator |
| Condenser type | web type condenser with fan |
| Interior Light | Yes, vertical (LED light is optional) |
| Key/Lock | Yes |
| Temp. Control | mechanical (digital thermostat is optional) |
| Defrosting | manual |
| glass fog removing | hot wind blowing |
| shelf (qty) | 3pc | 4pc | 4pc | 4pc |
| eletrical spec. | Refrigeratant | R134a / R600a |
| Input power (Kw) | 210 | 250 | 280 | 280 |
| Energy Consum.(Kw.h/24h) | 1.6 | 1.85 | 2.2 | 2.3 |
| Foam Blowing Agent | cyclopentane C5H10 |
| Voltage/frequency | 220V/50Hz, 220V/60Hz or 110V/60Hz |
| Compressor brand / origin | Donper/China Aspera/China |
| Load qty | 20FT/40FT/ 40HQ | 40 / 80 / 104 | 27 / 57 / 75 | 27 / 57 / 75 | 27 / 57 / 75 |
