| Prod Model: |
S1003 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Map: |
Stored in Memory or SD Card |
| 3G: |
Support 3G WCDMA 3G Dongle |
| Media: |
DVD/DVD-R/DVD+R/DVD-RW/DVD+RW/CD/CD-R/CD-RW/MP3/MP |
| Map Formate Support: |
Google Map Online, Sygic, Igo, 3D Maps, etc. |
| Combination: |
WiFi |
| Placement: |
Dashboard |
| Certification: |
ISO |
| Voltage: |
12/24V |
| Audio Output: |
L/R Channel |
| Video Output: |
Video |
| Resolution: |
1024*600 |
Product Description
Special Features:
Android 4.4.4 System
CAPACTIVE HD 1024X600 Screen
1080P HD Video
CPU: Rockchip 3066 Cortex A9 Dual-Core 1.6GHZ Frequency
1G DDR3 RAM Memory
Built In 8GB Inand
Built-In DVR Function With External Camera
External Bluetooth Microphone
Built-In WIFI Module
Support External 3G Dongle
Built-In Navigation With 3D Map (Map In Inand )
Quick Response After Lighting The Car: Within 1 Sec For Starting, Within 2 Secs For Sound,Within 3 Secs For Rearview,
Within 25 Secs For Operation When Tons Of Applications Installed
APE Music
Support HD 2D & 3D Games
Front And Rear Camera Can Work Together
Support Thousands Of Softwares Downloading From Android Market
Support SD/MMC/SDHC SD Ports, SDHC Supports Max 32G, HDD
Bluetooth Supports All Brands Cellphones,Phonebook Input,Music Playback, Supports Name Search By A-Z
Video Support: WMV(VC1 Code)AVI (H.264, MPEG4,Xvid, WMV),MP4 (H.263, H.264, MPEG4), MPG(MPEG-2),M4V(H.264, MPEG4)
| Configuration |
| OS | Android 4.4 system |
| CPU | Cortex A9 Dual Core |
| RAM | DDR3 1GB |
| Flash | Built in 8GB/16GB |
| Video Decode Support | 1080P |
| Touch Screen | Capacitive touch screen |
| GPS |
| Map | Stored in memory or SD card |
| Map Formate Support | Google map online, Sygic, IGO, 3D maps, etc. |
| Media Player | Yes |
| Card Supported | Normal SD card (Micro SD Card) |
| INTERNET |
| 3G | Support 3G WCDMA 3G dongle |
| Wi-Fi | Support Wi-Fi USB Dongle (external Wi-Fi receiver included in the package) |
| Android Apps Installation | Yes |
| Display Screen |
| Screen Type | Digital TFT touchscreen |
| Resolution | 1024*600 |
| Screen Dimension | 7 inch 16:9 |
| Wall Paper | live wallpaper |
| GUI Interface | 3D Interface |
| Language |
| Main Interface Language | English, Deutch, Franch, Portuguese, Spanish, Italian, Espanol,etc. |
| DVD Control Language | English,Francais,Spainish,Italian,Portuguese,etc. |
| DVD Playback |
| Disk Format Supported | DVD-Video, DVD±R/RW, DVD-ROM, CD-DA, CD-ROM, CD-R, CD-RW |
| Media | DVD/DVD-R/DVD+R/DVD-RW/DVD+RW/CD/CD-R/CD-RW/MP3/MP4(DIVX)/VCD/SVCD |
| Bluetooth |
| A2DP | Yes |
| Microphone | Built-in MIC |
| Received Call | Yes |
| Dialled Call | Yes |
| Missed Call | Yes |
| Download Contacts | Yes |
| Store Contacts | Yes |
| TV Tuner |
| Built-in Analog TV | Yes |
| Analog TV System | NTSC, PAL-B/G, PAL-I, PAL-D/K,PAL-M,PAL-N |
| Built-in DVB-T Tuner | Yes (Optional) / No |
| DVB-T Format | MPEG-2,Support 120km/h, 1 x Active Antenna Included |
| Built-in ISDB Tuner | Yes (Optional) / No |
| Radio |
| AM Frequency Range | 522-1620 (Europe), 530-1710 (America) |
| FM Tuning Range | 87.5-108 (Europe), 87.5-107.9 (America) |
| RDS | Yes |
| iPod Control |
| Touchscreen Control | Can Control Music Through Touchscreen |
| Show Information Of Music | Yes |
| Play Video | No |
| Storage Media |
| SD Card Slot For Music/Movie | Micro SD Card Slot |
| MAX Memory Supported 32GB |
| USB Port For Music/Movie | Mini USB Port |
| MAX Memory Supported 32GB |
| Position: Front Panel |
| Portable HD | Yes |
| Video & Audio |
| Video Input | 1-Channel RCA Input |
| Video Output | 2-Channel RCA Output |
| Audio Input | 2-Channel RCA Input |
| Audio Output | 4.1Channel RCA Output |
| Reverse Camera Input | Yes |
| 3 Zone Out | No |
| Other Functions |
| 2-Zone | Yes (Listen Radio/CD While Watching GPS Image) |
| 3-Zone | No (Listening To Radio/Watching GPS Image At The Front And Watching DVD/SD/USB/TV
From The Sub-monitor Simultaneously) |
| Pictrue In Pictrue | Yes |
| Steering Wheel Control Function | Yes |
| CANBUS | No |
| MFD | No |
| TMC | No |
| V-6 Disc Changer Memory | No |
| CDC | No |
| Parking Assistance | No |
| Game | Yes |
| Button Back Light | Blue Illumination |
| Accessories |
| User Manual*1,Power Cable*1,Remote Control*1,iPod Control Wire*1, RCA Cable*1,GPS Antenna*1,USB Cable*1 |
Serves Technology Limited covers an area of 1500 square meters and employs 100 people. With 3 years of experience in design, manufacture, marketing and customer service, we have become car video experts. We have several production lines for TFT LCD monitors, giving us an output of 35, 000 units monthly.
Our company has accounting, international sales, production, and customer service teams, as well as an engineering staff with over 5 years' experience in the Korean and Taiwan TFT monitor fields. They trace the entire production process, including design, molding, and mass production. In addition, we offer comprehensive OEM and ODM services for customers. Our professional engineers will finish the requested items for you based on drafts or ideas.
Our mission is to pursue and promote "popular functions, novel designs, high quality and tailor-made service". Our factory is ISO9001 certified due to our strict quality guarantee system. Our company has doubled its effort to develop overseas market-oriented cooperation, upholding the principle "high quality, high efficiency, high performance, high return".
We strive to provide satisfying products and services to our customers, which has been made possible by our professional personnel and sophisticated facilities. In the future, we will continue to devote ourselves to long-term business development and cooperation with our esteemed clients from all over the world.
