S100 – platform design request – function Description
|
|
Main function |
Basic function Description
|
system update
|
no need other special tools, you can update all software such as UI / MCU by sd card . |
Built in touch adjustment
|
support |
Time adjustment & display
|
support adjust system time by GPS |
Car Logo changing
|
support |
|
Audio function set up |
audio balance set up, high/ mid/bass setup
|
POP/Classical / Jazz
|
|
|
|
Video function set up |
Lightness / contrast / color adjustment
|
Support style set up
|
|
Dual zone |
DVD TV AUX Video output, 1 chanel CVBS video output, DVD TV AUX optional
|
Dual zone audio harness output, stereo harness output, TV AUX IPOD RADIO DVD for optional; can also select Bass for main channel output
|
Add dual zone control adaptor
|
|
Bass output |
Separated output
|
|
iPod function |
Belongs to main-board, auto display when connects to IPOD device
|
Video playing ( not support currently, but there is port ready for future)
|
Support audio playing, name display , album , singer's information
|
|
DVD function |
Car Spec DVD loader
|
Build in virtual disc ( 20 disc) changer
|
support DVD\DVD-R\DVD±RW\HDCD\CD-R\CD±RW\MP3\MP4\Picture CD\VCD\WMA
|
|
AUX function |
2 channel, support front & rear AUX input ( alternative)
|
|
TV function |
Support analog TV, support all TV system
|
DVB-T ISDB CMMB Support digital TV, DVB-T ISDB CMMB, support 2 tuners
|
Analog TV & digital TV – alternative.
|
|
Radio |
Build in car spec AM/FM tuner
|
support RDS
|
99 station preset for AM
|
99 station preset for FM
|
support local & long-distance
|
support to scan different frequency station by area step
|
|
Bluetooth |
support built in MIC
|
support external MIC, standard adaptor, no MIC wire
|
support BT 2.0, A2DP, support phone book
|
support calling record, support BT music
|
support phone book, calling recall
|
support phone book transferred
|
phone book language is the same as the cell phone
|
|
POP |
support POP
|
|
GPS |
Build in high quality GPS module,gain satellite signal faster and stable
|
support GPS signal query
|
GPS audio can be work together with front & rear speakers
|
TMC
|
|
Rear camera |
1 channel video input
|
Enter camera menu once in reverse
|
support device on when the car in reverse
|
|
light detect |
Auto detect car light to clarify day / night.
|
Auto on/ off for button light & screen lightness
|
|
hand brake detect |
There is " Safe driving" shown on the screen once this function is "ON"
|
|
steering wheel control |
2 channel for learning the steering wheel control code
|
support high / low resistance mode during learning.
|
|
External digital TV box |
DVB-T, CMMB, ISDB, support external digital TV box - DVB-T, CMMB, ISDB,support double digital tuner. Build in / external is alternative.
|
|
audio harness output |
FL FR RL RR support FL FR RL RR 4 channel output.
|
|
External USB ( 2 channel, 1 A output electric current |
USB1:USB2.0, USB1:USB2.0,for media playing, photos reading.
|
support WMV,AVI,MPEG,MP3,MP4,RMVB(1080P),JPEG format, support name , album , singer's name
|
USB2 – for 3G internet or WIFI input
|
|
SD SD card |
SD 1 – for Navigation, support SD2.0 protocol standard SDHC, support 32 GB. Support map data
|
support SD 2 – for media playing and photo reading.
|
support WMV,AVI,MPEG,MP3,MP4,JPEG, support name , album , singer's name
|
|
Game |
build in games
|
|
tooling |
build in normal tools, calculator, calendar.
|
|
GOD |
support
|
|
USB mouse keyboard |
external USB keyboard & mouse for convenient operation
|
|
Video recording |
can record DVD, AUX , TV
|
|
File magement |
build in flash and external SD, USB for data transferred
|
|
Operation guard |
with e- user manual inside
|
|
One key regeneration |
will support later
|
|
External TMC |
support
|
|
World time |
support
|
