| Prod Model: |
RO lab plus |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Motive Force: |
Electric power |
| Type: |
Reverse Osmosis |
| Usage: |
Environmental Protection, Chemical Industry |
| Flow Rate: |
30 Liter/Hour* |
| Instant Flow Rate: |
>1.5 Liter/Min(Need Storage Tank) |
| Dimension/Weight: |
Lengthxwidthxheight:41X22X42cm/About20kg |
| Electrical Requirements: |
100-250V, 50-60Hz/300W |
Product Description
Application
Ultra-pure water fill the system, glass washing, agricultural experiment, and aquaculture
The ordinary biology experiment, constant temperature wet equipment, humidifier and autoclave optimizations water
Flow schematic PF+AC+RO+AC
LV. 1 Special spun fiber filter
LV. 2 Special active carbon filter
LV. 3 Special active carbon filter
LV. 4 100 GPD RO membrabe
Performance characteristics
Domestic exclusive a injection molding import plastic case, sanitation PP plastic material,appearance is delicate
Case can be rapidly unscrew cover, realize unpacking can quick change without advance, accord with GLP standard filter column
Automatic pressure sensor control work, flush RO membrane automatically, tap water off the water automatic stop
The system would stop working, when the tank is full
The pipeline adopted quick swap interface, pipes, fittings all through the approval
with standard fast insert external equipment supply mouth, system can upgrade
After-sales
· The products customers buy from our company enjoy repair service since the day of purchase. In on year from the purchasing day, our company is obliged to replace components free of charge due to non-human-behavior factors except:
(1). Damage caused by maloperation or use in abnormal situations.
(2). Disassembly any part of the machine or human-behavior damage.
(3). Not repaired by our serviceman.
Main Market
Asia, The Middle East, Eastern Europe and South Africa
Certificates
Related link
http://www.high-tech.cn/prodetail_en.asp?id=1&lii=3
|
Specification |
RO system |
RO deionized system |
|
Model |
RO lab |
RO lab plus |
RO DI/RO DI digital |
RO DI plus/RO DI digital plus |
|
Flow procedure |
PF+AC+RO+AC |
PF+AC+RO+AC |
PF+AC+RO+DI |
PF+AC+RO+DI |
|
Application |
Ware washing, Agricultural expe, General biological expe, Aquatic products feeding, Inlet water for Ultra pure water machine, Inlet water for sterilizer/T&H chamber |
Buffer disposing, Physical and chemical analysis, Fine chemistry industry, GC/HPLC, Inlet water for Ultra pure water machine, Aseptic drinking water |
|
Feed water requirement |
Tap water: TDS<200ppm,5-45 degrees centigrade,1.0-4.0Kgf/cm 2
(if inlet TDS>200ppm, extra pretreatment is recommended) |
|
Purification system |
Pretreatment unit |
Special spun fiber filter×1+Special active carbon block filter×1+Special active carbon block filter×1 |
|
RO unit |
100GPD RO membrane×1 |
100GPD RO membrane×2 |
100GPD RO membrane×1 |
100GPD RO membrane×2 |
|
Subsequent unit |
Post active carbon filter×1 |
Mixed bed resin cartridge×2 |
Mixed bed resin cartridge×3 |
Pure water
quality |
Desalination rate% |
>95% |
>95% |
|
TDS |
5-10 ppm* |
RO water:5-10 ppm* |
|
Resistivity |
- |
15-18.2MΩ.cm |
|
Conductivity |
- |
0.067-0.055µs/cm |
|
Output(25 degrees centigrade ) |
15 liters/hour* |
30 liters/hour* |
15 liters/hour* |
30 liters/hour* |
|
Flow rate |
2 liters/min(with pressure tank) |
|
Pure water outlet |
RO water |
RO water, deionized water |
|
Control system |
Automatic electronic pressure sensor controlling, RO membrane auto flushing, automatic stop without water, automatic stop when water tank full, automatic cutting off water when pump stopping, guaranteeing 24 hours' work. |
|
Water quality monitor |
TDS test pen |
TDS test pen +on-line resistivity monitor |
|
Electric requirements |
AC110-220V,50/60Hz, 48W plus model:72W |
|
Dimension and weight |
Length×Width×Height:41×22×42cm / 12-14kg |
|
Standard configuration |
Main body(including:1 set cartridge)+4.0 gallon water tank + TDS pen + accessory box |
Hitech Instruments Co., Ltd, established in 2003, specializes in manufacturing laboratory water purification systems and related apparatus. Except for the small capacity lab water purification systems, we also provide the service of large or medium-sized water treatment engineering design, complete supply, installation debugging, technical reform and technical training etc. In addition, we can provide the professional training of the lab water knowledge, and optimize the existing water purification system to help customers to reduce the cost and guarantee the stable pure water supply.
With tap water inlet, integrating various advanced water purification technologies and process control methods, our water purification systems can completely meet, even exceed, the pure water standard of ASTM, NCCLS Class I etc. It can meet the meet of advanced lab water use for different purpose. It can be widely used in the field of chemistry, biology, pharmacy, medicine, micro-electronics, semiconductor etc, meeting the application requirements of spectral analysis, chromatographic analysis, cell culture, protein purification and molecular biology.
We will constantly bring in new technology, and devote ourselves to the development of new products in order to cover diversified demands from clients. We will provide comprehensive solutions for the lab pure water with professional pre-sales support and impeccable after-sales service.
We aim to integrate products with the world market, establish first-class brand by excellent quality and gain market shares by top brand.
