| Prod Model: |
CT-B01-A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Working Voltage: |
DC12-24V |
| Channels: |
3CH |
| Type: |
Joystick |
| Application: |
LED Products |
| Signal Transmission: |
IR Remote Control |
Product Description
Advantage:
1\Auto adaptation of 12-24V DC working voltage and with input polarity protection function
2. The newest PWM control technology, delicate light performance, no flicker
3. High power dimmer control MOS tube with stable and reliable performance, strong power-drive ability with max. 18A of 3 channels.
4\The input brightness remains the same as the output brightness
5 The input and output signal of power amplifier are equipped with the protection function of 5KV photoelectric isolation.
General Specifications:
Input voltage: DC12V~24V
Maximum current: 6A*3CH 18A MAX
Output channel: 3CH
Output power: 216W/432W(12V/24V)
Control mode: PWM
Output mode: Common anode
Output control mode: Constant voltage
IP: IP20
Circuit protection: Input polarity protection
Working temperature: -20~60
Product size: L73× W77.5× H33mm
Packing: L206.5× W136× H43mm
Weight: 134.4G
