| Prod Model: |
500LPH |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Motive Force: |
Electric power |
| Type: |
Reverse Osmosis |
| Usage: |
Environmental Protection, Water Treatment |
| Membrane: |
USA Dow Membrane |
| Certificate: |
CE |
| Voltage: |
AC380 50Hz or 220V 50Hz |
| Power: |
1.5kwph |
| Name: |
Professional Water Treatment System |
| Capacity: |
500L/H |
Product Description
Auto and manual wash
Auto power on and power off
Short circuit protection
Recovery rate50%-75%
salt rejection97%
Reverse osmosis (RO) is a membrane-technology filtration method that removes many types of large molecules and ions from solutions by applying pressure to the solution when it is on one side of a selective membrane. The result is that the solute is retained on the pressurized side of the membrane and the pure solvent is allowed to pass to the other side.
2. Stages of Filtration:
1). Sediment Stage: Removes rough particles, sand and rust.
2). Quartz sand stage: Lower the turbidity of feed water (NTU)and sludge density index (SDI) values
3). Carbon stage: Removes chlorine and chemicals which would otherwise damage the membrane.
4). Resin stage: Purolite ion-exchange.
5). Reverse osmosis stage: Removes dissolved solids and all that are bigger than water molecule.
6. )Final Carbon stage: To improve the taste
7). Ozone sterilization: To kill microorganisms.
8). Storage tank
9. )UV sterilization: To kill microorganisms.
3. Advantage
1). Can production water continuously and highly automatic
2). No need the chemical regeneration, easy operation
3). RO system choose the import USA DOW membrane
4). Automatic switch on when low water level, and switch off when high water level
5). RO membrane can backwash automatic and reduce thepollution.
6). Water shortage protection for multi-stage pump
7). Porduction water condutivity meter can test the monitoring quality on line contionuosly.
8). Low operation Cost and Long life span
9). Easily control and Maintained.
10). Auto membrane flushing
11). Environmental protection, Low power consumption
12) Auto flush/backwash
13) Low /high pressure protection
|
Model No. |
Capacity (M3/H) |
Power (kw) |
Recovery Rate (%) |
Total land area LX W X H (mm) |
|
RO-250 |
0.25 |
1.5 |
50 |
2500X1000X2800 |
|
RO-500 |
0.5 |
1.5 |
50 |
2500X1000X2800 |
|
RO-1000 |
1 |
2 |
50 |
3500X1200X2800 |
|
RO-2000 |
2 |
4 |
50-60 |
6500X1500x2800 |
|
RO-3000 |
3 |
4.5 |
55-65 |
7500X1500X2800 |
|
RO-4000 |
4 |
6.5 |
55-65 |
7500X1500X2800 |
|
RO-5000 |
5 |
11 |
60-70 |
10000X2500X3500 |
|
RO-6000 |
6 |
11 |
60-70 |
10000X2500X3500 |
|
RO-8000 |
8 |
18 |
60-70 |
10000X3500X3500 |
|
RO-10000 |
10 |
20 |
60-70 |
10000X4000X3800 |
|
RO-20000 |
20 |
30 |
70-75 |
15000X5000X5000 |
|
RO-30000 |
30 |
40 |
70-75 |
20000X6000X5000 |
|
RO-50000 |
50 |
50 |
70-75 |
30000X8000X5000 |
