| Prod Model: |
RO-1000J(6000L/H) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Performance: |
Efficient Filtration |
| Type: |
Reverse Osmosis |
| Motive Force: |
Electric Power |
| Style: |
Vertical |
| Usage: |
Environmental Protection, Chemical Industry |
| Material: |
S.S.304 |
| Capacitity Of Water Production: |
6000 Liter Per Hour |
| Capacity: |
6000L/H |
Product Description
Reverse Osmosis Water Purifier for Drinking Water
Water purifier, water treatment equipment, water purification machine.
Company Overview
Shine Dew Water Equipment Co., Ltd. is a specialized manufacturer of drinking water treatment equipment, auto bottling machines, labeling machines and other auxiliary equipment, with more than 10 years of experience in China. We have exported our machines to Central and South America, Africa, the Middle East and Southeast Asia. Furthermore, we have completed many turnkey projects of water treatment factories for our customers from the above-mentioned regions. Moreover, we can also provide turnkey services for water bottling plants and beverage production plants.
Our goal is to assist our customers to provide healthy water for human beings. We sincerely hope to develop together with our customers in the field of water treatment industry. We welcome your contact via email, telephone and fax. We will always do our best to serve you.
(1)Technical Parameters
Technical specification:
No. | Item | Model | Specification | Qty | Origin |
| 1 | Feed pump | CHLF16-40 | SS304, 380V/50Hz 4KW | 1set |
|
| 2 | Quartz sand filter | S.S. Φ1200*2200mm | 2000kgs refining quartz sand | 1set |
|
| 3 | active carbon filter | S.S. Φ1200*2200mm | 1000kgs coconut carbon | 1set |
|
| 4 | Water softener | S.S. Φ1200*2200mm | UK PUROLITE Resin | 60bags | UK |
| 5 | Control valve | F77A | F77A | 3 pcs | RUNXIN |
| 6 | Salt tank | / | 400L | 1Set |
|
| 7 | Micron filter | Φ350*1000mm | Stainless steel, 5um PP filter*15 | 15pcs |
|
| 8 | RO device | MJ-36K | 6T/hr 25°C | 1set |
|
| 9 | 1st high pressure pump | CDLF12-140 | SS304, 380V/50Hz 11KW | 1set | CNP |
| 10 | RO membrane | BW30-365 | minimum salt rejection rate: 99.5% | 6pcs | DOW,USA |
| 11 | pressure vessel | FRP 8040*2 | FRP | 3pcs |
|
| 12 | Magnetic valve | / | / | 2pcs |
|
| 13 | Adjustable valve | / | / | 1pcs |
|
| 14 | Flow mete | / | / | 2pcs |
|
| 15 | Low pressure gauge | / | / | 2pcs |
|
| 16 | High pressure gauge | / | / | 2pcs |
|
| 17 | Pipeline | / | PVC-U |
|
|
| 18 | PLC control | / | / | 1set |
|
| 19 | Ultraviolet sterilizer | / | 40W*3items | 2sets |
|
| 20 | C.I.P. system | / | Famous brand, China | 1set |
|
| 21 | Electrical control | LG series | SS304 electrical cabinet with connector | 1set |
|
| 22 | Protection system | High pressure pump protection without water |
(2) Products Description
RO system refers to reverse osmosis system, the most advanced technique in water purifying machine.
This Equipment can be design for both small and large scale water factory according to the output.
A variety of protective measures are designed to defend system in case of poor power, larger electrical current, no power, short circuit, creepage of electricity etc.
(3)Functions and Characteristics
Pure water to clean, clear, and sterile
All equipment chemicals are supplied
All equipment accessories are provided
Ro membranes include auto wash and manual wash
Minimal manual supervision on account of automatic
Provide plant design and operating instructions are provided
Protective measures when poor power, larger electrical current, no power, short circuit, creepage of electricity etc.
(4)Useful for
Factory and water bottle filling production
Hotel drinking water supply
Farm water supply
Many other applications
(5)Before Design
1. We need you to advise us what kind of drinking water that you want to manufacture. Is it pure water, mineral water or beverage?
2. We need you to tell us the kind of your source water, and you need to provide us Source Water Testing Analysis Report.
3. Please tell us the production capacity of the machine that you demand, so that we can recommend the suitable machine to you and present quotation solution for you.
4. Please tell us the type of electric Voltage, Frequency in your country.
(6)Shine Dew Products catalog
1. Reverse osmosis water purification equipment
2. Ultra filtration systems for mineral water and spring water
3. Auto water filling machines for 3/5 gallon bucket and small bottle (0.35-1.5L)
4. Packaging machines, like labeling machines and date printing machines
5. Bottle blowing machines for small PET bottles
6. Make budget for customers; building water treatment factories as per clients' request
7. Factory layout design, machine installation and adjustment and operation technology training.
