Product Description
Reverse Osmosis Water Purifier
Feature
This is Reverse Osmosis water purifier for producing drinking water. The system apply advance PLC control system to achive full automatic run for the process of pure water production, flushing and back washing. The main frame of the machine is made or high quality 304 stainless steel, and the electric elements is from famous internation brand, the key component RO membrane is America DOW FILMTEC to ensure that the system is reliable and with high efficiency.
Technical process
Raw water--Raw water tank-- Raw water pump-- Sand filter-- Active carbon filter-- Security filter-- high pressure pump-- RO component-- Pure water tank-- UV/Ozone-- Pure Water
1 ,
|
raw water Pump
|
1unit
|
|
Model :
|
CHL4-30
|
Brand :
|
Nanfang
|
Power :
|
0.75KW
|
Voltage :
|
380V
|
Flow volume :
|
4m3/h
|
Height :
|
32m
|
Material :
|
304 stainless steel
|
2 ,
|
Multi-media filter
|
1set
|
|
Operation method :
|
manual
|
Filter tank :
|
|
material :
|
Stainless Steel
|
Model :
|
400*1650
|
Pressure resistance :
|
0.5Mpa
|
Mark :
|
With manual valve, distribute the water up and down
|
Filling material
|
|
Material :
|
Precision quartz sand
|
Specification :
|
10-24
|
Quantity :
|
As demand
|
3 ,
|
Active carbonated filter
|
1set
|
Operation method :
|
Manual
|
Filter tank :
|
|
material :
|
Stainless Steel
|
Model :
|
400*1650
|
Pressure resistance :
|
0.5Mpa
|
Mark :
|
With manual valve, distribute the water up and down
|
Filling material
|
|
Material :
|
Active carbon
|
Specification :
|
10-24
|
Quantity :
|
As demand
|
4
|
Sodium ion-exchanging device
|
1set
|
Operation method :
|
Manual
|
Filter tank :
|
|
material :
|
Stainless Steel
|
Model :
|
400*1650
|
Pressure resistance :
|
0.5Mpa
|
Mark :
|
With manual valve, distribute the water up and down
|
Filling material
|
|
Material :
|
Active carbon
|
Specification :
|
10-24
|
Quantity :
|
As demand
|
|
|
5 ,
|
Security filter
|
1set
|
5-1
5-2
|
Model :
|
5 cores 40 inches
|
Material :
|
304 stainless steel
|
Origin :
|
Hangzhou
|
Water output rate of the filter
|
2T/H
|
Core filter
|
5 pieces
|
Specification :
|
40 inches
|
Material :
|
PP cotton
|
Main engine
|
1set
|
1
|
Model :
|
2-40
|
|
Brand :
|
nanfang
|
Power :
|
0.75
|
Voltage :
|
380
|
2
|
RO
|
|
Model :
|
4040
|
Brand :
|
Hydranautics USA
|
Amount
|
10
|
3.
|
Pressure meter
|
|
Specification :
|
1.0mpa/3.0mpa
|
Material :
|
Immerse in oil, stainless cover
|
Origin :
|
Yuyao
|
4
|
Flow volume meter
|
2 units
|
Specification :
|
LZM-35
|
Material :
|
plexiglass
|
Origin :
|
Jiangsu
|
5
|
Equipment frame
|
1 set
|
Specification :
|
1050x700x1650mm
|
Material :
|
Stainless steel
|
Origin :
|
AK-MACHINE
|
Zhangjiagang City Ak Machinery Co., Ltd. Which is located in Zhangjiagang, east to Shanghai, west to Nanjing, along to Changjiang River, with convenient transportation.
Our company is a research and development, production, sales and technical service specialized in one Drinking Water and Beverages equipment manufacturers. The company mainly produces beverage production line equipment, beverage equipment sterilization, pure water production line, sleeve labeling machine and packaging machinery. Products are sold to more than 30 provinces, municipalities, autonomous regions and exported to Southeast Asia, Africa and Europe. After more than a decade of development and accumulation of the Company in fruit juice production line, tea drinks production line, carbonated beverage production line, pure water production line, dairy production line, automatic filling machine, beverage sterilization machine, sleeve labeling machines and shrink packaging machines, etc. In the domestic industry has made technological lead. Warmly welcome friends old and new customers, colleagues come to our factory inspection, visit and business negotiation figure leaps and bounds.
Main Products:
The capacity of 2000--40000 BPH for hot filling, MID-temp filling producing line.
The capacity of 2000--40000 BPH for mineral water and purified water producing line.
The capacity of 2000--36000 BPH for carbonated beverege producing line.
The capacity of 150--1200 TBH, for 3 gallon, 5 gallon producing line.
All kinds of water treatment equipment.
PET perform inject and blowing-stretching machine. Mould plastics machine
Turn-key projects
