| Prod Model: |
RS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Performance: |
Low Noise |
| Type: |
Piston |
| Drive Mode: |
Electric |
| Piston Type: |
Closed |
| Configuration: |
Stationary |
| Power Source: |
AC Power |
| Material: |
Carbon Steel |
| Lubrication Style: |
Lubricated |
| Mute: |
Not Mute |
| Application: |
Back Pressure Type |
Product Description
Copeland Piston Refrigerator CompressorQuick Details
- Type:Refrigerator Parts
- Place of Origin:Zhejiang, China (Mainland)
- Brand Name:RESOUR
- Condition:New
Packaging & Delivery
| Packaging Details: | carton |
|---|
| Delivery Detail: | 30 days |
|---|
Dimension:
Feature:
1. Low noise
2. High efficiency
3. Wide range of application
4. High start efficiency
5. High temperature resistance
6. Reliable work performance
R12/R406a Commercial series compressor
| MODEL | HORSE POWER | Displ. | CAPACITY(W) @ Condensing Temp. 54.5ºC/130ºF | INPUT POWER |
|
| cm³ | -35 | -30 | -25 | -23.3 | -20 | -15 | -10 | -5 | 0 | @-23.3ºC |
| RS43 | 1/8HP | 4.3 | 63 | 74 | 96 | 108 | 140 | 185 | 235 | 305 | 398 | 105 |
| RS52 | 1/6HP | 5.2 | 85 | 95 | 120 | 132 | 163 | 210 | 260 | 355 | 440 | 122 |
| RS59 | 1/6HP+ | 5.9 | 90 | 100 | 130 | 142 | 175 | 235 | 285 | 405 | 465 | 125 |
| RS65 | 1/5HP | 6.5 | 115 | 125 | 155 | 170 | 210 | 280 | 335 | 435 | 550 | 145 |
| RS75 | 1/4HP | 7.5 | 120 | 130 | 160 | 180 | 225 | 290 | 380 | 510 | 630 | 155 |
| RS91 | 1/4HP+ | 9.1 | 128 | 147 | 198 | 215 | 265 | 375 | 470 | 615 | 735 | 175 |
| RS110 | 1/3HP | 11.0 | 175 | 195 | 238 | 280 | 340 | 455 | 555 | 665 | 785 | 225 |
| RS128 | 3/8HP | 12.8 | 195 | 220 | 305 | 355 | 440 | 540 | 680 | 810 | 1020 | 280 |
| RS142 | 1/2HP | 14.2 | 215 | 255 | 335 | 385 | 470 | 560 | 725 | 860 | 1100 | 305 |
| RS158 | 1/2HP+ | 15.8 | 225 | 290 | 395 | 440 | 525 | 655 | 820 | 950 | 1180 | 345 |
R134a Commercial series compressor
| MODEL | HORSE POWER | Displ. | CAPACITY(W) @ Condensing Temp. 54.5ºC/130ºF | INPUT POWER |
|
| cm³ | -35 | -30 | -25 | -23.3 | -20 | -15 | -10 | -5 | 0 | @-23.3ºC |
| RS43H | 1/8HP | 4.3 | 65 | 76 | 98 | 110 | 142 | 188 | 245 | 320 | 402 | 105 |
| RS52H | 1/6HP | 5.2 | 87 | 98 | 122 | 134 | 165 | 215 | 265 | 358 | 446 | 122 |
| RS59H | 1/6HP+ | 5.9 | 95 | 105 | 135 | 145 | 180 | 240 | 295 | 415 | 480 | 125 |
| RS65H | 1/5HP | 6.5 | 115 | 125 | 155 | 170 | 210 | 280 | 335 | 435 | 550 | 145 |
| RS75H | 1/4HP | 7.5 | 125 | 135 | 165 | 185 | 230 | 290 | 380 | 510 | 630 | 155 |
| RS91H | 1/4HP+ | 9.1 | 135 | 155 | 205 | 220 | 270 | 380 | 475 | 625 | 750 | 175 |
| RS110H | 1/3HP | 11.0 | 185 | 205 | 245 | 285 | 345 | 460 | 570 | 680 | 800 | 225 |
| RS128H | 3/8HP | 12.8 | 205 | 235 | 320 | 360 | 445 | 550 | 695 | 830 | 1050 | 280 |
| RS142H | 1/2HP | 14.2 | 240 | 270 | 350 | 395 | 485 | 590 | 755 | 890 | 1150 | 305 |
| RS158H | 1/2HP+ | 15.8 | 275 | 310 | 405 | 450 | 540 | 680 | 855 | 980 | 1250 | 345 |
R600 compressor
| MODEL | HORSE POWER | Displ. | CAPACITY(W) @ Condensing Temp. 54.5ºC/130ºF | INPUT POWER |
|
| cm³ | -35 | -30 | -25 | -23.3 | -20 | -15 | -10 | -5 | 0 | @-23.3ºC |
| RS65Y | 1/8HP | 6.5 | 70 | 81 | 103 | 112 | 131 | 167 | 212 | 268 | 318 | 80 |
| RS75Y | 1/6HP | 7.5 | 77 | 93 | 117 | 132 | 146 | 181 | 240 | 300 | 360 | 91 |
| RS85Y | 1/5HP | 8.5 | 81 | 100 | 132 | 145 | 173 | 216 | 268 | 332 | 396 | 100 |
| RS91Y | 1/5HP+ | 9.1 | 86 | 113 | 145 | 158 | 191 | 241 | 290 | 363 | 438 | 105 |
| RS103Y | 1/4HP | 10.3 | 97 | 123 | 155 | 168 | 200 | 253 | 305 | 374 | 448 | 116 |
| RS110Y | 1/4HP+ | 11.0 | 110 | 138 | 173 | 186 | 225 | 287 | 363 | 450 | 537 | 128 |
| RS128Y | 1/3HP- | 12.8 | 127 | 158 | 200 | 218 | 270 | 350 | 430 | 478 | 558 | 145 |
| RS142Y | 1/3HP- | 14.2 | 136 | 171 | 220 | 138 | 295 | 380 | 468 | 555 | 640 | 158 |
| RS153Y | 1/3HP+ | 15.3 | 150 | 195 | 250 | 268 | 328 | 423 | 515 | 610 | 705 | 168 |
| Test Condition | LBP | MBP |
| 1. Evap.Temp | -23.3ºC(-10ºF) | 0ºC(32ºF) |
| 2. Ambient Temp. | 32.3ºC(90ºF) | 35ºC(95ºF) |
| 3. Cond.Temp | 54.5ºC(130ºF) | 54.5ºC(130ºF) |
| 4. Suction Temp. | 32.3ºC(90ºF) | 35ºC(95ºF) |
| 5.Subcooled Temp. | 32.3ºC(90ºF) | 35ºC(95ºF) |
Technical data changing range:
1. Capacity≥95%
2. Input Power≤115%
3.Cuttent≤110%
4. COP≥93%
Compressor Dimension:
| Model | RS43H RS65Y RS52H RS75Y | RS59H RS85Y RS65H RS91Y | RS75H | RS91H RS103Y RS110H RS110Y | RS128Y RS142Y | RS128H RS153Y | RS142H | RS158H |
| H(mm) | 174 | 180 | 190 | 197 | 190 | 196 | 196 | 198 |
| L1(mm) | 205 | 205 | 225 | 225 | 243 | 243 | 243 | 243 |
| L2(mm) | 149 | 149 | 155 | 155 | 162 | 162 | 162 | 162 |
| P/I.D (mm) | 5.2±0.1 | 5.2±0.1 | 5.2±0.1 | 6.4 (5.2)±0.1 | 6.4±0.1 | 6.4±0.1 | 6.4±0.1 | 6.4±0.1 |
| X/I.D (mm) | 6.4±0.1 | 6.4±0.1 | 6.4±0.1 | 6.4±0.1 | 6.4±0.1 | 6.4±0.1 | 6.4±0.1 | 6.4±0.1 |
Compressor Wiring Diagram
Ordering Model:
