Hangzhou Qianjiang Compressor Co., Ltd. >> R600A Refrigeration Compressor for Refrigerator Ws91yv

R600A Refrigeration Compressor for Refrigerator Ws91yv

R600A Refrigeration Compressor for Refrigerator Ws91yv
Price: US $ 1-100/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1000/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: WS91YV-6
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color: Black
Status: New
Type: Piston
Performance: Low Noise
Drive Mode: Electric
Power Source: AC Power
Configuration: Stationary
Material: Copper
Piston Type: Closed
Lubrication Style: Lubricated

Product Description










RSCR Motor

Use R600a refrigerant

Compressor working condition: Wansheng R600a series compressors can start and run under the 0.25Mpa(gauge) balance pressure and 85% rated voltage; Under special conditions voltage low to 165V and high to 242 is allowable.

Strictly processed refrigerant oil has been authorized by Wansheng Compressor to add into R600a compressor. It is not allowed to pour out or add randomly, otherwise all technical assurance would be invalid.

R600a compressor must use PTC starting relay.

Low vibration

Low noise

High efficiency

High reliability

Good start-up performance

High stability

Voltage application from 220 to 240V

Frequency only for 50HZ

Low Back Pressure

Starting device is PTC

Application in refrigerators, freezers, display cabinets, wine chests, etc.

Piston compressor WS91YV especially suit for refrigerator

WS91YV has passed CCC/CE/CB/VDE certification

R600a WANSHENG Low Back Pressure(LBP) Compressor
Wansheng R600a Low Back Pressure(LBP) compressorTest ConditionsEvap. Temp.: 7.2°C



Cond. Temp.: 54.4°C





Amb. Temp.: 32.2°C



Suction. Temp.: 35°C





Subcooling Temp.: 46.1°C



LBP ASHRAE





   Model                        Power SupplyDisplacement (cm³)Cooling Capacity  (W)Rated Power   (W)       Nominal power     (HP)  COP  (W/W)Motor TypeCapacitor (μF)Starting RelayCooling Type
WT Series
WS91YV220-240V/50Hz9.1158931/81.7RSCR4PTCS

Founded in December 1994, Hangzhou Qianjiang Compressor Co., Ltd., is specialized in producing hermetic compressors for refrigerators, freezers and various household appliances. Due to attaching great importance to technical innovation and development of new products, the company owns a technical team to pursue the excellent and constant self-development.
