We are a leading supplier of Purified cube ice making maker machine in the world market. We are engaged in supplying high quality products, competitive prices and customized services for our customers. Up to now, we have exported our vending machines to more than 30 countries and regions. The main overseas markets are: the USA, Mexico, Bolivia, Uruguay, the Netherlands, Denmark, France, Indonesia, etc.
Brief introduction of Purified cube ice making maker machine
1) Fully automatic water purification, ice making, ice vending and calculation of ice amount and price, really realize the fully automatic vending.
2) LED display screen, online display sum and balance;
3) Payment methods: coin +bill +IC card
4) Turnover can be checked, independent counting for coin and card
5) Ice tank foamed from 5cm thickness polyurethane have good heat preservation function so as to ensure ice cube will stay for a long time without melt.
6) Adopt global advanced American MEI/COINCO currency payment system, that is stable and reliable.
7) Adopt German SIEMENS/GSM module to realize the machine remote management: automatic message notification when failure; check turnover and running status by message
8) Adopt Taiwan FOTEK photo electricity switch induction technology to check ice position, automatically stop vending when lack of ice.
9) In auto packing structure, we adopt German SIEMENS PLC (programmable logic controller) which is imported with original package. And German imported vacuum suction nozzle, stable transmission, can move ice, bag ice, seal bag, dispense rapidly and automatically
10) Adopt American EVERPURE filters to produce sanitary edible ice cube.
General introduction of Purified cube ice making maker machine
1) Model of Purified cube ice making maker machine: 900kg model
2) Capacity of Purified cube ice making maker machine: 900KG/24H
3) Storage of Purified cube ice making maker machine: 150KG
4) Size of Purified cube ice making maker machine: W145×D130×220cm
5) Cooling system of Purified cube ice making maker machine: water/air
Main Parameters of Purified cube ice making maker machine
NO | Item | Parameters |
F-13 ice vending machine |
| | |
1 | capacity of ice in20°C | 900KG/D |
2 | Spec of compressor | 5P |
3 | Power supply | AC220-240v/50-60HZ, AC110v/60Hz |
4 | consumption | 5KW |
5 | rated current | 23A |
6 | Environment temperature | 2-38°C |
7 | Working temperature | 20°C |
8 | Size of the ice-cube | 2.2cmx2.2cmx2.2cm |
9 | Capacity of ice mould space | 540 |
10 | refrigerant | R404A |
11 | Cooling method | Spray cycling spray |
12 | Radiating method | Air (can customize water cold) |
13 | Size of bulk ice tank | W65cm×D45cm×45cm |
14 | Capacity of ice tank | 150KG |
15 | Material of ice tank | Stainless steel 304 |
16 | Purification process | Tap water→20″5upp filter→20″1upp filter→EVERPURE filter→ice machine |
17 | Dispensing ice | Bulk Ice/Bag Ice |
18 | bag ice | 1-7kg |
19 | Bag Size | 40cm×60cm/38cm×60cm |
20 | Capacity of inside storage bag | 300 |
21 | Machine size | L145cmxW130cmxH220cm |
