| Prod Model: |
PM320DSn |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
CE, FCC, RoHS |
| Model: |
Pm320dsn |
| Diagonal Size: |
32" |
| Aspect Ratio: |
16:9 |
| Pixel Pitch: |
0.17(H) X 0.51(W) |
| Response Time: |
8ms |
| Resolution: |
1366X768 / 1920X1080 |
| Contrast Ratio: |
1200:1 |
| Memory: |
DDR3 1gbyte |
| SD Card: |
Max 32g |
| Type: |
Network Version AD Player |
| Application: |
Indoor/Semi Outdoor Ad Player |
Product Description
Main Functions
1. Support 1920X1080 HD video decoding.
2. Built-in 4G memory
3. Support SD card expansion up to 32G.
4. Video, pictures Mixture no black, flash switching.
5. On/off timer switch, according to a daily or weekly settings.
6. Variety of image transition mode, transition effects and picture playback interval time can be set freely by software.
7.100 playlists, according to a preset time to play.
8. Video, pictures automatically rotate, without using other tools for editing.
9. Support horizontal and vertical screen arbitrary split screen, you can achieve 1 video, 4 pictures, 1 marquee, 1 logo, 1 date, 1 time, 1 background-exist.
10. U disk broadcast programs, U disk can also be copied to the built-in memory programming for playback.
11. Encryption mode can be set by programming tools and terminal settings to achieve the program encryption, It will not play without the correct key.
12. Display the playlist by USB disk.
13. Support for subtitles rolling: Font color, font size, rolling speed settings defined by the user
14. Support USB upgrade the system and screen parameters.
15. Designed and engineered for 24/7 operation. Long lifetime: >50, 000 hours.
16. Energy saving, very eco-friendly low power.
|
LCD panel |
|
|
Diagonal Size |
32" |
|
Aspect Ratio |
16:09 |
|
Pixel Pitch |
0.17(H) x 0.51(W) |
|
Response Time |
8ms |
|
Resolution |
1366x768 / 1920x1080 |
|
Contrast Ratio |
1200:1 |
|
Brightness (cd/m2) |
350d/m2 |
|
Active display area |
698(H) x 392(V) |
|
Display Color (Max) |
16.7M |
|
Viewing Angle(U/D,L/R) |
H:178o V:178o |
|
System software |
|
|
System software |
Android 4.2.2 |
|
Network mode |
|
|
Lan |
10M/100M |
|
WIFI |
802.11g/n |
|
3G |
Need 3G module |
|
Support format |
|
|
Video format |
MPEG1\MPEG2\MPEG4\H.264\WMV\AVS, VC-1,RV, VP6/VP8, Sorenson Spark, MVC |
|
Audio format |
MP3 |
|
Image format |
JPG\JPEG\BMP\PNG\GIF |
|
Speaker |
|
|
Speaker |
2*2W |
|
Parameters |
|
|
CPU |
Dual Core ARM Cortex A9 1.5GHz |
|
GPU |
4*Core ARM Mali-400 MP |
|
Memory |
DDR3 1Gbyte |
|
SD card |
Max 32G |
|
USB interface |
USB2.0 * 1 |
|
Internal Storage |
FLASH 4G |
|
Audio output |
Stero CLASS-D, Support:8Ω 2x10W |
|
3G module interface |
PCIE*1; USB*1 |
|
WIFI |
WIFI(150Mbps)*1 |
|
Lan |
10/100M |
|
Video output |
VGA×1\HDMI×1 |
|
Audio output |
3.5mm Phone Jack |
|
Extensible interface |
Serial port * 1; SPI *1;Camera * 1;USB(for touch) * 1 |
