| Prod Model: |
CA Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Oceania,Eastern Asia,Western Europe |
| Function: |
Amplifier Combined |
| Tube Type: |
Tube Amplifier |
| Voltage: |
AC 220V |
| Element Number: |
Push-Pull Amplifier |
| Output Number: |
8 |
| Used For: |
Professional |
| Conductive Mode: |
AB |
| Usage: |
KTV System |
Product Description
CA series amplifier include traditional protection functions: Short circuit, over current, DC output, soft start, current fuse protection, transformer overheating protection, transformer, overheating protection.
This series have the higher from 2U to 3U, The power is from 150W to 1350W on 8 ohms. The pursult of faster response, higher damping, more features, more advanced protection system Designed has excellent heat dissipation air duct way, a compact and solid mechanical seismic performance, SMT production technology, sophisticated components. CA series can withstand stereo 2ohms bridge 4 ohms load, suitable for line array speaker system.
Model CA2 Stereo power8 Ω 250Wx2, Stereo power4 Ω 400Wx2, Bridge power8 Ω 500Wx1, Output Circuity ClassAB, Power Requirements 110V, 120V, 220V, 240V, 50-60Hz, Dimensions(LxWxH) 487X454X88mm
Model CA4 Stereo power8 Ω 350Wx2, Stereo power4 Ω 600Wx2, Bridge power8 Ω 700Wx1, Output Circuity ClassAB, Power Requirements 110V, 120V, 220V, 240V, 50-60Hz, Dimensions(LxWxH) 487X454X88mm
Model CA6 Stereo power8 Ω 500Wx2, Stereo power4 Ω 800Wx2, Bridge power8 Ω 1000Wx1, Output Circuity ClassH, Power Requirements 110V, 120V, 220V, 240V, 50-60Hz, Dimensions(LxWxH) 487X454X88mm
Model CA9 Stereo power8 Ω 600Wx2, Stereo power4 Ω 950Wx2, Bridge power8 Ω 1200Wx1, Output Circuity ClassH, Power Requirements 110V, 120V, 220V, 240V, 50-60Hz, Dimensions(LxWxH) 487X454X88mm
Model CA12 Stereo power8 Ω 800Wx2, Stereo power4 Ω 1500Wx2, Bridge power8 Ω 1500Wx1, Output Circuity ClassAB, Power Requirements 110V, 120V, 220V, 240V, 50-60Hz, Dimensions(LxWxH) 510X489X132mm
Model CA18 Stereo power8 Ω 1000Wx2, Stereo power4 Ω 1800Wx2, Bridge power8 Ω 1200Wx1, Output Circuity ClassAB, Power Requirements 110V, 120V, 220V, 240V, 50-60Hz, Dimensions(LxWxH) 510X489X132mm
Model CA20 Stereo power8 Ω 1300Wx2, Stereo power4 Ω 2500Wx2, Bridge power8 Ω 2600Wx1, Output Circuity ClassH, Power Requirements 110V, 120V, 220V, 240V, 50-60Hz, Dimensions(LxWxH) 510X489X132mm
