Pm2.5 Car Air Purifier for Mercedes Benz B200 (1698300218)

Prod Model:	OEM no. 1698300218
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Structure:	Long Fiber + Activated Carbon + Long Fiber
Fiber Material:	Colbond Long Fiber
Carbon Material:	Coconut Shell Activated Carbon
Production Method:	Injection Molding Process After Folding The Filter
Working Life:	6 Months(It Depends on The Working Environment)
Type:	Cabin Filter
Material:	Activated Carbon
Structure:	Filter Element/Assy
Application:	Air
Brand:	Plow

Product Description

PM2.5 Car Air Purifier for Mercedes Benz B200(1698300218)


Car Model	Mercedez Benz B20 Fashion
OEM No.	1698300218
Huadi No.	PC-M0218T
Usage	Air filter
Function	Air filter, purification filter
Transfer Function	Cabin filter
Structure	Filter Element/Assy
Type	Auto Filter
Material	Activated carbon
Carbon Material	Coconut shell activated carbon
Fiber Material	Colbond infinite long fiber
Product Structure	Long fiber+activated carbon+long fiber
Production Method	Injection molding process after folding the filter
Dimension	388*181*32mm

The Activated Carbon Filter Technical Data
Model	Weight(g/m²)	Thinkness(mm)	Filtration Efficiency(%)	Air Permability(mm/s)	Iodine Absorb(mg/g)	CTC Absorb(%)	Hardness(%)	Moisture(%)	Density(g/I)
500Z	500±7%	2.0±0.2	95.0	1,000	900	39	98	8	600-650
550F	550±7%	2.0±0.2	95.0	1,100	900	39	98	8	600-650
550Y	550±7%	3.5±0.3	95.0	1,200	900	39	98	8	600-650
550S	550±7%	1.5±0.2	93.0	1,100	900	39	98	8	600-650


What is a Cabin Air Filter?
The cabin air filter is a high particulate filtration medium that is attached to the outside air intake of your vehicle's ventilation system. This device helps to improve air quality and filter out pollution from the air that circulates inside the vehicle. Most air filters are made from a pleated paper construction, using a variety of different filtration media. Some are a cotton and paper blend, while others are basically extremely miniaturized paper filters similar to the air filter of your car's intake system. There are some that are just a formed and shaped cotton filter in a cartridge.


The cabin air filter is sometimes confused with an internal combustion air filter. The internal combustion air filter is the filter under your hood that prevents particles from getting into the engine. A driver may encounter the internal combustion air filter as a service recommendation at an oil change shop. That's because if the air filter gets clogged or otherwise compromised, it can affect engine performance.

It's important to recognize the distinction between these two very different types of air filters. When buying cabin air filters, you're looking for something that's going to help improve the air that you will be breathing as a driver or passenger in the vehicle. It's not so much part of the vehicle's performance gear as a health and safety device. Drivers can consider buying "green air filters" that are more sustainable and include more attention to what the inhabitants of a vehicle will be breathing.


Where is the Cabin Air Filter Located?
The cabin air filter, or air conditioning filter, is located in different places in different cars. On some cars these are easy to locate, remove and change. On others, they are more difficult to remove and change. They will all be in the air conditioning/vent system after the fan. Most of these can be found just inside a small inspection door in the cabin side of the fan housing. On most cars this will be down by where the front seat passenger's feet are located. This area is sometimes referred to as the foot well. Refer to your car's manual for the exact location.



Is the AC Filter the Same as the Cabin Air Filter?
Yes. Some manufacturers call these filters AC filters (or air conditioning filters), while others call them cabin air filters. Either way, they are the same thing and they perform the same function of removing dust and other allergens from the air entering the passenger compartment.


Is Changing Your Cabin Air Filter Really Necessary?
A dirty cabin air filter can cause your air conditioner to run less efficiently, which will waste horsepower. It will also decrease the amount of air flow into the passenger compartment. Both of these conditions will result in higher temperatures in the passenger compartment and the air conditioner having to work harder than it really needs to. Changing the cabin air filter in your vehicle is not only important from a maintenance perspective, but also helps ensure the safety of the passengers in your vehicle. The cabin air filter is a very important part of your car's ventilation system and removes many common pollutants from the air, thus protecting the passengers inside the vehicle.

Step-By-Step Guide For Auto Cabin Air Filter Replacement

STEP 1
Open the glove box.
Open the glove box and take out the contents.

STEP 2
Remove the limiting stop arm.
The limiting stop arm is on the right side of the glove box. Just slide it off the pin.

STEP 3
Release the glove box.
Grasp the front and back of the glove box, squeezing them toward each other until the side clamps pop free. Now that the sides are free, you can drop down the entire glove box, so you can see the faceplate to the cabin air filter channel.

STEP 4
Remove the old cabin air filter.
Lift the latches on the sides of the faceplate and slide it out of the way, opening up the filter compartment. Now you can simply pull out the old cabin air filter, being careful not to scatter any dust, dirt and trash from the filter into your car. As you remove the old filter, notice which way the arrows are facing. They indicate the direction of the airflow.

STEP 5
Clean filter chamber and check seals and gaskets.
Before you install a fresh, new HUADI PLOW cabin air filter, vacuum the filter chamber, then wipe it with a damp cloth to remove any stray contaminants. Check the condition of gaskets and seals to make sure they don't need changing as well.

STEP 6
Install the new cabin air filter.
Make sure the new cabin air filter matches the old one. Double check to make sure the arrows on the new filter are pointing in the same direction as the old filter you took out, and slide the new filter in.

STEP 7
Replace and secure the glove box.
Once the filter's in place, just replace the faceplate, snap the glove box back in place, reinstall the limiting stop, and put everything back in the glove box.
