| Prod Model: |
IF3T-R4A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Ice Flake Maker |
| Certification: |
CE |
| Condition: |
New |
| Ice Shape: |
Flake Ice |
Product Description
ICESTA PLC touch screen controlling ice flake makerAlways used in the industrial field such as field aquatic food & meat product processing, leather, fowl butchering, dye chemical industry, mines, concrete construction project, etc.
Advantage:A. Low failure and long working life: The System always runs well more than 35000 hours
B. Perfect stability: In normal condition remains good output, and the special types run well in execrable conditions.
C. High efficiency & capacity
D. Superior safety and reliability: Dynamic micro-computer control system
E. Low energy consumption Power supply: 3P/ 380V / 50HZ The ice thickness: 1.5-2.2 mm You can chose the different types to meet your request. 1) Cooled Model: Air-cooled, and Water-cooled 2) Refrigerant: R22/ R404A / R717
|
Model |
IF3T-R4A |
IF3T-R4A |
|
Technical parameters |
bitzer |
BOCK |
|
Compressor Model |
12HP |
12HP |
|
Ice production |
3t/24h |
3t/24h |
|
Refrigeration Capacity (KW) |
17.41 |
18.3 |
|
Evaporating Temp (C) |
-20 |
-20 |
|
Condensing Temp (C) |
40 |
40 |
|
Total power (KW) |
10.81 |
11.84 |
|
Compressor Input Power (KW) |
9.67 |
10.7 |
|
Reducer Power (KW) |
0.37 |
0.37 |
|
Evaporator Pump Power (KW) |
0.09 |
0.09 |
|
Condensing Fan Power (KW) |
0.68 |
0.68 |
|
Power Supply |
3P/380V/50Hz |
3P/380V/50Hz |
|
Feed in water pressure |
0.1-0.5Mpa |
0.1-0.5Mpa |
|
Refrigerant |
R404a |
R404a |
|
Flake ice Temp |
-5 |
-5 |
|
Thickness of Ice |
1.5-2.2mm |
1.5-2.2mm |
|
Standard Ambient Temp |
25 |
25 |
|
Standard water feed temp |
20 |
20 |
|
Water Consumption (M3/h) |
0.125 |
0.125 |
|
Feeding tube |
1/2" |
1/2" |
|
Net weight of unit |
600KG |
600KG |
|
Dimensions of unit (mm) |
1700*1200*1200 |
1700*1200*1200 |
|
Size(With bin) |
1700*1635*2785 |
1700*1635*2785 |
