| Prod Model: |
OEM |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Min. IC Pitch: |
0.30mm(12mil) |
| Foot Pin: |
So, Sop, Soj, Tsop, Tssop, Qfp, BGA and U-BGA |
| Min. Chip Placement: |
01005 |
| Max. PCB Size: |
410mm X 600mm(16.2" X 23.6") |
| Min. PCB Thickness: |
0.35mm(13.8mil) |
| Maximum BGA Size: |
74mm X 74mm(2.9" X 2.9") |
| BGA Ball Pitch: |
1mm ~ 3mm(4mil ~ 12mil) |
| BGA Ball Diameter: |
0.4mm ~ 1mm(16mil ~ 40mil) |
| Qfp Lead Pitch: |
0.38mm ~ 2.54mm(15mil ~ 100mil) |
| Layers: |
1 ~ 30 Layers |
| Base Material: |
FR-4 |
| Metal Coating: |
Copper |
| Mode Of Production: |
SMT or DIP |
Product Description
ItemsCapability
1Min. IC Pitch0.30mm(12mil)
2Foot PinSO, SOP, SOJ, TSOP, TSSOP, QFP, BGA and U-BGA
3Min. Chip Placement 01005
4Max. PCB Size410mm X 600mm(16.2" X 23.6")
5Min. PCB Thickness0.35mm(13.8mil)
6Maximum BGA Size74mm X 74mm(2.9" X 2.9")
7BGA Ball Pitch1mm ~ 3mm(4mil ~ 12mil)
8BGA Ball Diameter0.4mm ~ 1mm(16mil ~ 40mil)
9QFP Lead Pitch0.38mm ~ 2.54mm(15mil ~ 100mil)
10PackageAnti-static Bubble Bag & Carton
PCB Capability
ItemsCapability
1Layers1 ~ 30 layers
2Base MaterialFR4, High Tg FR4, Halogen Free, Isola, Rogers, Aluminium
3Finished Board Thickness0.2mm ~ 7.0mm(8mil-276mil)
4Copper Thickness1/3oz ~ 7oz
5Surface FinishingHASL, Lead Free HASL, Immersion tin, Immersion gold, Gold plating, Immersion silver, OSP, Carbon, etc.
6Reference StandardIPC-A-600H Class 2, Class 3, TS16949
7CertificateUL, ISO9001, RoHS, SGS
8PackageVacuum & Carton
FPC Capability
ItemsCapability
1TypesSingle-sided, Double-sided, Multi-layers (max 6 layers) and
Flex-Rigid PCB
2Surface FinishingHASL(LF), Gold plating, Electroless nickel immersion gold, Immersion Tin, OSP(Entek)
3Base MaterialPolyimide(Kapton), Polyester(PET), FR4
4Soldering Thermal Resistance300° C/10 seconds
5Performance Test100% electrical and electricity performance test
|
Incoming Quality Control |
|
make inspection according to International Standard and customer requirements. |
|
|
|
In-Process Quality Control |
|
Standard manufacturing process and detailed work instructions for each operation station in production line to make sure that operation standard are implemented correctly. |
|
|
|
Outgoing Quality Control |
|
We inspect and control strictly the outgoing products quality according to the international standards and customer standards, follow up the quality performance of products after sales and take rapid and effective improvement actions when there are any abnormal quality feedbacks. |
|
|
|
Product Return Process |
|
1. Contact us about the defect within 2 weeks upon receiving the products |
|
2. Send detailed digital photos and description of the defect. |
|
3. Wells engineers will review your request and if the products are non-conforming per customer specifications or correlative standard,we will process your request. |
|
4. Upon your approval,we will address the problem and re-run your order based on the original order request.There will be no additional charge. |
|
5. If you quality for a refund,we will refund 100% of your order amount,not including shipping costs. |
|
|
|
|
|
Our service |
|
1. Your inquiry related to our products or prices will be responded within 24 hours. |
|
2. Well-trained and experienced staffs to answer all your enquiries professional. |
|
3. OEM & ODM are welcomed, ODM brand is available. |
Welcome to contact us, all your inquiry will be replied within 24 hours.
Wells Electronic Technology Ltd. Established in 2000, located in the largest electronic market-Shenzhen, is a professional PCB & PCBA manufacturer with One-stop Service. With 13 years experience, Wells Electronic can provie you PCB design, PCB manufacture, components procurement and PCB assembly services.
PCB Manufacture:
Wells is a leader in the manufacture of high-tech printed circuit boards. We specialize in fabricating high precision, high density and high reliability PCB from 2 to 30 layers. We are certified with ISO9001: 2000 and UL approval. All products will be RoHS compliance.
PCB Assembly:
Wells has professional purchasers who are on the component market. Our factory is equipped with MPM solder paste printer, Siemens D-series high-speed chip shooters, YAMAHA high-speed chip shooters, BTU reflow furnaces and a full set of lead-free equipments. We can deal with all kinds of integrated circuits such as SO, SOP, SOJ, TSOP, TSSOP, QFP, BGA and U-BGA.
PCB Design:
Wells has gathered a large number of engineers who are outstanding in the domestic circuit design industry and have over 10 years of experience in design. We have specially set up LED products design, mobile phone design project group, notebook design project group, backplane design project group and communication products project group, etc.
No order is too small or too large. Welcome you to require a quote!
