Shenzhen Myled Optech Co., Ltd. >> Pantallas Gigantes De LEDs, Pantallas LED Display

Pantallas Gigantes De LEDs, Pantallas LED Display

Pantallas Gigantes De LEDs, Pantallas LED Display
Price: US $ 1/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 5/Square Meter
Pay Type: L/C,T/T,Western Union
Prod Model: MY-P10-1R1G1B
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pantallas Gigantes LED: Video Pantallas LED Outdoor
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Pitch: 10mm
Pixel Configuration: 1R, 1G, 1B
Display Function: Video Display
Average Power Consumption: 220W / m²
Pixel Density: 10000 dot / m²
Scanning Mode: Static Scan
Display Type: LED Video Display
Application: Advertising
Certification: ETL

Product Description

Tenenos una larga gama de pantallas.
Outdoor :P10mm, 16mm, 20mm, etc
Indoor: 4mm, 5mm, 6mm, 7.62mm, etc

Somos un fabricante de profesional de pantallas gigantes de Leds.

No sólo nuestro precio y la calidad es muy bueno, pero también es muy rápido y conveniente de comprar con nosotros.Nuestro plazo de entrega es de dos semanas.Nuestro producto es de primerisima calidad.Podemos ofrecer un servicio de post-venta rapido y excelente.


Además, tenemos ingenieros que hablamos español.
[email protected]


Main Parameter
Category
Parameter
Pixel Pitch
10mm
Optimum Viewing Distance
10-25m
Density of Pixel
10000pixels/
Brightness
≥5000nite
≥6500nite
Module Resolution
32*32
LED Encapsulation
DIP346 1R1G1B
SMD5050 1R1G1B
Driving Method
Real 4 Scan
Real 2 Scan
Optimum Viewing Angle
H: 110°V:50°
H: 120°V:100°
Module Size
320*320*28.4(mm)
160*160*22.5(mm)
Module Power
50w
70w
Module Weight
1200g
1100g
Cabinet Size
960*960*178.4(mm)
960*960*173(mm)
Cabinet Resolution
96*96
Cabinet Power
1125w
1100w
Cabinet Weight
55kg
49kg
IP Rating
Front/Rear:IP65/IP43
Refresh Rate
1000-4000Hz( Different according to the different Driving IC )
Luminance Consumption
Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature25ºC.
MTBF
>5000hours
Defective Dot Rate
<0.0001
Life Span
>100000hours
Working Voltage
110-240 AC±10% 50-60Hz
Working Temperature/Humidity
-30ºC- +50ºC/10-90%RH
Storage Temperature/Humidity
-40ºC- +60ºC/10- 90%RH
Input Signal
RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Connector
CAT5 Cable(Length≤1430m),Optical link(Length≤20km,Optional)
Note: The above parameter is just for reference. Changes can be made according to customers' requirements.

Located in Baoan District, Shenzhen Myled Optech is an professional LED display manufacturer which is dedicated to LED display R&D; Production, sales, marketing and one stop solution for customers mainland and international. Myled provides consulting, installation, training and sales services for customers. We always regard customers as the company life line.

Shenzhen Myled Optech focus on indoor and outdoor full color LED display, LED curtain display, mesh, indoor and outdoor single and bicolor LED display manufacturing. We have established business relationship with customers in South America, Euro, and Asia etc. And win a good reputation among customers all over the world. And we provide full solution for Government, Telecom, Hotel, airport, bus station, stadium, and cinema and financial center, etc. Over the past years, we have finished some important LED display project for South American and China Mainland.

Quality is the most important theme for Myled and welcome to contact, and visit our company.

We hold the truth that better quality, better price and better sales services are our company culture.
