| Prod Model: |
p5-smd |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Life Span: |
>100, 000hours |
| Mtbf: |
>10, 000hours |
| Average Power Consumption: |
400W/M2 |
| Delivery Time: |
3-12working Days |
| Module Size: |
320*160mm |
| Max Refresh Rate: |
2800 |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Pitch: |
5mm |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Density: |
40,000 dots / m² |
| Scanning Mode: |
1/8 Scan |
| System Operating Platform: |
WIN XP |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| IP Rating: |
IP43 |
| Certification: |
CCC |
Product Description
Usage;
LED display is widely used in finances, post offices, telecom, commerce, hospitals, stadiums, shop, plaza, concert, fashion shows, exhibitions and so on.
Features and advantages;
1. Your inquiry related to our products or price will be replied in 24hours
2. OEM&ODM price, ex-work price, factory price, FOB price, CIF price.
3. Products of various specs and models may be ordered at your requirement.
4. Our engineers are free to help installing and adjusting display.
Our factory professionally manufacture follow products,
1) Single color LED display, dual color LED display, and full color LED display.
2) Indoor LED display semi-outdoor LED display and outdoor LED display.
3) LED moving sign, LED message sign, LED sign, programmable LED moving message sign board, variable message signs, electronic message sign, LED scrolling message signs, LED text display.
4) LED display screen, LED display board, LED display module, LED display cabinet.
5) LED video display, LED advertising display, truck mobile LED display, rental LED display, stadium LED display, concert LED display, and stage LED display.
6) Wireless LED display board, computer controlled LED display.
Warm Tip:
There is DIP, SMD, and Dotmatrix LED display for customer choosing.
LED display styles: P4, P4.75, P5, P6, P7.62, P8, P10, P12, P12.5, P14, P16, P20, P25, P31.5,
Numbers | Technical indexes | Specification |
| 1 | Pixel pitch | 5mm |
| 2 | Module size | 320mm×160mm |
| 3 | Module resolution | 64×32 |
| 4 | Module density | 40,000dots/sqm |
| 5 | Pixel configuration | RGB,3 in 1 |
| 6 | Red wavelength | 625±2nm |
| 7 | Green wavelength | 525±2nm |
| 8 | Blue wavelength | 470±2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 5m---150m |
| 11 | Horizontal viewing angle | 140° |
| 12 | Vertical viewing angle | 120° |
| 13 | Maximum power consumption | 1000W/sqm |
| 14 | Average power consumption | 500W/sqm |
| 15 | Brightness | 2500cd/sqm,adjustable |
| 16 | Gray scale | 16bits of per color |
| 17 | Color temperature | 12,000K |
| 18 | Driving method | 1/8scanning |
| 19 | Frame frequency | 60Hz |
| 20 | Refresh frequency | 300 Hz |
| 21 | Working voltage | AC220V/110V±10% |
| 22 | IP grade | IP20-45 |
| 23 | Working temperature | -20°C~80°C |
| 24 | MTBF | More than 10,000 hours |
| 25 | Life span | More than 100,000hours |
Website:http://www.foxgolden.com
Foxgolden had been engaged in designing and manufacturing LED display for more than 11 years. Our products have certificates like CE/FCC/RoHS/NQA .
The best quality products and excellent service will be provided to you by our professional team.
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
