P38 Outdoor Virtual Full Color Big LED Display
| Price: |
US $ 600-1200/Piece |
| Trade Terms: |
others |
| Min Order: |
1/Square Meter |
| Pay Type: |
L/C,T/T |
| Prod Model: |
P38 panting virtual full color LED display |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
CE/FCC/CCC/UL/RoHS |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
2R,1G,1B |
| Display Function: |
Video Display |
| Scanning Mode: |
Static Scan |
| Pixel Pitch: |
38 |
| Average Power Consumption: |
122 |
| Pixel Density: |
693 |
Product Description
We produce indoor LED display/ outdoor LED display/ Single color/ bi-color/full color LED display/ LED sign/ LED module for LED sign making
LED Lamp Specs
- Configurations: 2 Red, 1 blue & 1 Green.
- Viewing Angle: H=120, V=60.
--
Module Specs
- True Pitch=38mm;
- True Resolution=8 x 8; Virtual Resolution=16 x 16
- Module Dimensions=304mm x 304mm
--
Cabinet Specs
- Module Layout = 4 x 3
- Cabinet Dimensions = 1216mm x 912mm x 190mm
--
LED Display Specs
- Brightness: >4, 800nit
- Contrast: >64000: 1
- Grayscale: 64k
- Scan Rate: 1, 000Hz
- Refresh Rate: 60-85Hz
- Transformation: Virtual/True
- Maximum Resolution: 1024 x 768 / 1280 x 1024
--
Other
- The chips are 14mil LED display special chips, and they are antistatic for over 5000V.
- The copper brackets and silica gel have high quality, and they are electric, heat-dissipated, and anti-ultraviolet ray.
- Professional spectral and color separation standard have ensured the coherency of the display's color.
- The materials of PCB accord with the standards of UL certification, and the copper on them are over one ounce.
- All connectors are phosphor copper, and they are plating for 2μ , so they are acid-resistant and alkaline-resistant.
- The display is accordant with RoHS standards.
