| Prod Model: |
P3-16S |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Pixel: |
3mm |
| Module Size: |
192mm X 192mm |
| Module Weight: |
500g |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Configuration: |
1R,1G,1B |
| Scanning Mode: |
1/16 Scan |
| System Operating Platform: |
WIN XP |
| Display Type: |
LED Video Display |
| Application: |
Art Show |
| IP Rating: |
IP43 |
| Certification: |
ETL |
| Pixel Pitch: |
3mm |
| Pixel Density: |
111111dots/Dqm |
Product Description
P3 mm competitive price slim led module
1. Our Service
1)Your inquiry related to our products or price will be replied in 24hrs
2)OEM&ODM, any your customized lightings we can help you to design and put into product
3)Distributoership are offered for your unique design and some our current models
4)Protection of your sales area, ideas of design and all your private information
5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win
2. Trade Terms
1. Payment: T/T, 30% deposits before production, 70% balance to be paid before dleiverying
2. Shipping freight are quoted under your requests
3. Shipping port: ShenZhen, Mainland China
Product Description
Main Technical Parameters for Indoor Series |
Model |
P3-16s |
Pixel Pitch(mm) |
3 |
Physical Density(dot/m²) |
111,111 |
LED Configuration |
1R1G1B |
LED Type |
SMD2121 |
Model Size(mm*mm) |
192x192 |
Module Resolution( W*H) |
64 x 63 |
Drive Mode |
1/16 scan |
Brightness(cd/m²) |
≥1800 |
Max Power Consumption(W/ m²) |
1040 |
Average Power Consumption( W/m²) |
360 |
Cabinet Size(mm*mm) |
576 x 576 |
Cabinet Resolution(W*H) |
192x192 |
Mini. View Distance (m) |
2.5 |
View Angle(deg.) |
Horizontal≥120ºC,Vertical≥120ºC |
Grey Scale |
≥16 bits |
Refresh Rate( Hz) |
≥960 |
MTBF |
>10,000 hours |
Life Span |
≥100,000 hours |
Working Input Voltage |
AC220V/50Hz or AC110V/60Hz |
Module Display Brightness Uniformity |
<2% |
Earth Leakage Current |
<3mA |
Temperature-operating |
-25ºC~45ºC |
Humidity-operating |
10%~95% |
Operating System |
Windows98/me/2000/NT/XP/W8/Vista/W7 |
Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.
Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.
As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.
Main product list:
Indoor display, outdoor display, outdoor/indoor display mesh
Pixel pitch:
From P1.5, P1.875, P3.0, ...P31.25
Application locations:
Outdoor, Indoor and semi-outdoor
Application markets:
Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
