| Prod Model: |
FOX-P3 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Average Power Consumption: |
350W/M2 |
| Life Span: |
>100, 000hours |
| Mtbf: |
>10, 000hours |
| Delivery Time: |
3-12working Days |
| Product: |
P3 Full Color |
| Module Size: |
192*192mm |
| Module Dots: |
111111dots |
| Brightness: |
3000CD/M2 |
| IP Grade: |
IP45 |
| Horizontal Viewing Angle: |
140degree |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Configuration: |
1R,1G,1B |
| Scanning Mode: |
1/8 Scan |
| System Operating Platform: |
WIN XP |
| Display Type: |
LED Video Display |
| Application: |
Indoor |
| IP Rating: |
IP43 |
| Certification: |
RoHS |
| Pixel Pitch: |
3mm |
| Pixel Density: |
111111 |
Product Description
Usage;
LED display is widely used in finances, post offices, telecom, commerce, hospitals, stadiums, shop, plaza, concert, fashion shows, exhibitions and so on.
Features and advantages;
1. Your inquiry related to our products or price will be replied in 24hours
2. OEM&ODM price, ex-work price, factory price, FOB price, CIF price.
3. Products of various specs and models may be ordered at your requirement.
4. Our engineers are free to help installing and adjusting display.
Our factory professionally manufacture follow products,
1) Single color LED display, dual color LED display, and full color LED display.
2) Indoor LED display semi-outdoor LED display and outdoor LED display.
3) LED moving sign, LED message sign, LED sign, programmable LED moving message sign board, variable message signs, electronic message sign, LED scrolling message signs, LED text display.
4) LED display screen, LED display board, LED display module, LED display cabinet.
5) LED video display, LED advertising display, truck mobile LED display, rental LED display, stadium LED display, concert LED display, and stage LED display.
6) Wireless LED display board, computer controlled LED display.
Warm Tip:
There is DIP, SMD, and Dotmatrix LED display for customer choosing.
LED display styles: P4, P4.75, P5, P6, P7.62, P8, P10, P12, P12.5, P14, P16, P20, P25, P31.5,
Numbers | Technical indexes | Specification |
| 1 | Pixel pitch | 10mm |
| 2 | Module size | 320mm×160mm |
| 3 | Module resolution | 32×16 |
| 4 | Module density | 10,000dots/sqm |
| 5 | Pixel configuration | RGB,3 in 1 |
| 6 | Red wavelength | 625±2nm |
| 7 | Green wavelength | 525±2nm |
| 8 | Blue wavelength | 470±2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 8m---150m |
| 11 | Horizontal viewing angle | 140° |
| 12 | Vertical viewing angle | 70° |
| 13 | Maximum power consumption | 1000W/sqm |
| 14 | Average power consumption | 400W/sqm |
| 15 | Brightness | 10,000cd/sqm,adjustable |
| 16 | Gray scale | 16bits of per color |
| 17 | Color temperature | 12,000K |
| 18 | Driving method | 1/4scanning |
| 19 | Frame frequency | 60Hz |
| 20 | Refresh frequency | 300 Hz |
| 21 | Working voltage | AC220V/110V±10% |
| 22 | IP grade | IP20-45 |
| 23 | Working temperature | -20°C~80°C |
| 24 | MTBF | More than 10,000 hours |
| 25 | Life span | More than 100,000hours |
Our Services
1. Guarantee
(1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remand our goods for free if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materials only.
2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
3. Maintenance and Consultation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consultation by E-mail, call, MSN or other ways for free.
4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.
5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional service
(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
