| Prod Model: |
Outdoor Full-color P25 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brightness: |
More Than 8000CD/Sqm |
| Waterpoof: |
IP67 |
| Price And Advantage: |
Factory Price and LED Dotmatrix Display Manufactur |
| Warranty Time: |
7years |
| Programmable Card: |
Outdoor Video LED Display Panel |
| Colors: |
16777216 |
| Support Input Signal: |
HDTV CATV NTSC PAL S-Video VGA VCD DVD |
| Interface: |
Network/Erial Port/50 Chip/Parallel RS 232/Solar P |
| Delivery Detail: |
3-5working Days |
| Diode Model: |
Silan/Nichia/CREE/Epistar/Opto |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP67 |
| Pixel Pitch: |
25mm |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
350W / m² |
| Pixel Density: |
1600 dot / m² |
| Scanning Mode: |
1/16 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
RoHS |
Product Description
Feature and Advantage:
1. Wide application field & short ROI time: Commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instruction
2. High Contrast: 4000: 1, which is a very high level to ensure a vivid image of our LED display screen system...
3. First-class LED chip: Supplied by COTCO/CREE/AXT/SILAN/TAI WAN LED lamps to ensure the long lift-time and high brightness of our LED display screen system
4. Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROI of your LED display screen's investment.
5. Long-term Brightness: 9000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.
6. Easy Installation & Using: Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
7. Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
* Products function introduction: 1) High intensity and can be adjusted, so can meet the request of the customers according the application environment. 2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light 3) To pictures and character, have clear, exquisite and real display effect 4) Big viewing angle to 110 degree at horizontal line, 60 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion 5) Can repair each LED lamps, so the cost of maintain is lower, and easy to repair. * Products Advantages: 1) Price Advantage: We have the best competitive price at the market
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each LED lamps 3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability. 4) Service advantage: Better service at same situation, better cooperation at same service!
* Products list and application area: 1) Full color LED display: Equally or compactly make the red, green, blue color in one DOT, equally distribute at the panel, so make the whole display 2) Usually apply for physical sports, advertisement, bank, stock exchange, station, port, marketplace, telecommunication, department, school, monitor, restaurant, entertainment,
Service:
Provide free technology support by phone and e-mail
7 years guarantee
4. Delivery: Approx 3-12 working days
5. Packing: Anti-shaking wooden package or Air Flight Case
6. Transportation: By sea or air or Express
Currently, FOXGOLDEN LED display is already exported to Asia, Europe, South America, North America, Africa and Middle East and other regions. We attained ISO9001: 2000, CCC. CE, FCC, RoHS etc
For more details, please feel free to contact us. We will give you best service and timely reply
| P25 Outdoor Lamp Display Specification |
| Technical Specification |
| Pixel Pitch | 25mm |
| Density of Pixel | 1600dots/m 2 |
| Pixel configuration | 2R1G1B |
| Size of Single Board | 400mm200mm |
| Colors | 16777216 |
| Best Viewing Distance | ≥15m |
| Horizontal Viewing Angle | 140° |
| Maximum Power Consumption | ≤1000W/m 2 |
| Brightness | 6500cd/m 2 |
| Gray Scale | 14 bits per color |
| Color Temperature | 6500k |
| Control Method | to be synchronized with computer monitor |
| Driving method | 1/2 scanning |
| Frame Frequency | 60Hz |
| Refresh frequency | 3000Hz |
| Working Voltage | AC220V/110V±10% |
| IP grade | IP67 |
| Working temperature | 20degree centigrade +70 degree centigrade |
| Computer operation system | Win 98/ Win XP/ Win 2000 |
| Brightness adjustment | 256 grade manual, 8 grade automatic |
| Video signal | RF, S-Video, RGB, RGBHV, YUV, YC.ect |
| Software | LED play software |
| MTBF | More than 10000 hours |
| Life Span | 100,000 hours |
