| Prod Model: |
P6-8S-O |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Pitch: |
6mm |
| Waterproof: |
IP65 |
| Package Mode: |
SMD3535 |
| Brightness: |
6500-6800CD/Sqm |
| Viewing Angle: |
H:160 W:160 |
| Warranty: |
Full 2 Years |
| Life Time: |
More Than 100,000 Hours |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
300W / m² |
| Scanning Mode: |
1/8 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
CCC |
| Pixel Pitch: |
6mm |
| Pixel Density: |
27777dots/Sqm |
Product Description
P6 Outdoor Waterproof SMD Rental Full Color LED Wall Display Screen
Specifications
CLC Display Full Color Outdoor LED Display
1.CLC Display outdoor smd Full Color LED Display
LED Display, Indoor outdoor LED Display, Full color LED display:
P6 LED Display uses state-of-art LEDs, which has the brightness for indoor and outdoor application. The LED display has the advantage of excellent flatness, super uniform color and brightness. The LED Display has long viewing distance. The LED display cabinet of the rental LED display use aluminum which make the weight very light and easy to assemble.
Outdoor full color LED display could be used in outdoor environment such as cultural or relax square, commercial walking street, residential sub-district, downtown, etc. Place, with the speciality of dampproof, windproof, sunproof, staticproof, antifreezing, waterproof, its purpose is to propagandize outdoor advertising or play the important news or events or TV program, enrich the resident's cultural life, advance the whole visualization of sub-district, etc.
2. Features of the product:
1) High brightness and be adjustable, meets the need of the changing requirement of customer in environment.
2) Having good lightening accordance and no mosaic.
3) Using virtual pixels, better viewing effect for both text & graphic and video.
4) Having larger viewing angle: Horizontal angle 100 degree / elevation angle 45 degree. Getting vivid effect within any position of the viewing range.
5) Any led in each pixel can be respectively repaired, which reduce the cost of the display maitenance.
6) Good heat emission capability
7) Environmental-friendly.
3. Description:
1). Model No.: P10m, P12mm, P14mm, P16mm, P18mm, P20mm, P25mm, P31.25mm, (DIP LED)
2). Display Color: 256*256*256
3). Led Chips: Nichia, Cotco, Cree, AXT, Taiwan
4). Raw Materials: Toshiba IC, MBI IC, Chuanglian Power Supply, Meanwel Power Supply, Meanwel fans, ADDA fan, Beijing glue, Korean glue.
5). Cabinet: Standard cabinet, simple cabinet, customized cabinet, cabinet for rental, Iron or Aluminum cabinet, cabinet for front maintenance, cabinet with lock, Special cabinet with Southco Lock, for hung and rental and so on.
6). Package: Flight box, wooden box package
7). Guarantee: 1 year with parts
Module | Item | Parameter |
| Model Number | P6-8S |
| Module size | 192mm*192mm |
| Pixel pitch | 6mm |
| Pixels Density | 27777/m2 |
| Pixel configuration | 1R1G1B |
| Package mode | SMD3535 |
| Pixel resolution | 32dots(W)*32 dots(H) |
| Max Power | 20W |
| Module thickness | 17.05mm |
| Weight | 0.202kg |
| Drive type | Constant drive |
| Scan mode | 1/8scan |
| Port type | HUB75-A |
| Brightness of white balance | ≥6500cd/m2 |
