| Prod Model: |
Outdoor led mesh screen |
| LED Chip: |
CREE/Nichia/Epistar |
| Weight: |
≤18kgs/M2 |
| Brightness : |
≥7000CD/M2 |
| Permeation Rate: |
35% |
| Unit Size: |
1000mm(W)*500mm(H) |
| Viewing Angle: |
Horizontal: 120° Vertical: 60° |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
350W / m² |
| Scanning Mode: |
1/16 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
ETL |
| Pixel Pitch: |
15.625 |
| Pixel Density: |
4096 |
Product Description
Product Features
It can replace traditional P16 type
It is the most light and slim type among the similar products
Low carbon environmental protection
Stripe design,Slim and lightweight,Reduce drag,Good light transmission
Easy construction,front/rear maintenance,fast assembly and disassembly,single dismantle five seconds to complete
With power factor correction(PFC)+Synchronous rectification,Self-cooling design
Without any additional auxiliary cooling equipment
Using Range
Widely used in large venue,stadiums,bank,government,
terminal,dock,station,stock market,medical systems,
electricity,exhibition etc.
Parameters
The Technical Parameters of Outdoor led mesh screen
| Items | Parameter |
| Pixel pitch | 15.625mm |
| Led Chip | Cree/Nichia/Epistar |
| Pixel density | 4096dots/m2 (can replace traditional P16 type) |
| Pixel configuration | 1R1G1B |
| Maximum power consumption | 400W/m2 |
| Average power consumption | 200W/m2 |
| Weight | ≤18KGS/m2 |
| Brightness | ≥7000cd/m2 |
| Permeation rate | 35% |
| Unit Size | 1000mm(W)*500mm(H),thickness is 50mm |
| Viewing Angle | Horizontal: 120° Vertical: 60° |
| Protection Level | IP68/IP65 |
| Refresh Frequency | ≥1000Hz |
| Frame Rate | ≥60Hz |
| Working Temperature | (Work :-35ºC~+50ºC) |
| Relative Humidity | 10% ~ 90% |
| Grey Scale | Unique 14bit,True colors,Restore lifelike picture |
| Control Distance | Cat5 cable: 100m Single optical fiber: <10km |
HongKong Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.
Features:
1) With good lightening accordance and no mosaic
2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment
5) Uses real pixels rather than virtual pixels, better viewing effect
Applications:
LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
