Mounting LED Smart Touch Screen /Interactive Touch Screen

Prod Model:	HV70
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	50", 55", 65", 70", 75", 84"
Visual Angle:	178
Contrast:	1600:1
Interface Type:	Serial, USB, HDMI, Composite Video
System Support:	Android/Win7/Win8/Win10/Linux/Mac
Touch Points:	2 Points, 10 Points Touch
Touch Resolution:	32767*32767
Resolution:	1080P, 4k
OEM Service:	Yes
Screen Size:	>60 Inches
Aspect Ratio:	16:9
Application:	Education and Training System
Screen Type:	Infrared
Customized:	Non-Customized
Resistive Touch Screen Type:	Infrared

Product Description

Brief description:
1.32 touch points,10 writing points
2.infrared touch screen monitor
3.all in one pc
4.finger or pen or any opaque object can touch, no need special pen
5.Anti-glare whiteboard surface, protect eyes

Specification:
Hot sale 10 points writing Open Cell waterproof touch screen monitor wifi,  touchscreen all in one PC monitor with good prices

LED Specifications
Available size: 50", 55", 65", 70",75", 84"
Below is the specification of 84" touch screen monitor.

LED Parameters	Size	84.04"
	LED Brand	LG
Packing Parameters	External Size	1963.02*1149.02*90.3mm
	Touch Size	1904.0(h)x1096.0(v)mm
	Carton Size	2160*350*1340mm
	Net Weight	120kg
	Gross Weight	135kg
Power Parameters	Power	< 800W
	Standby Power	<1W
Display Parameters	Active Display Area	1904.0(h)*1096.0(v)mm
	Pixel Pitch	0.4845 mm * 0.4845 mm
	Display Colors	10bit(D), 1.06Billon colors
	Number of Pixels	3840*2160 pixels
	Brightness	350cd/m2
	Viewing Angle	178 Degree
TV Parameters	TV Standard	NTSC M/N,PAL BG/DK/I/H,SECAM L/L
	Multimedia Formats	MPEG1,MPEG2,MPEG4,H264,RM,RMVB,MOV,MJPEG
	USB2.0 Multimedia Playback	Vido/Audio/Picture
	USB System Upgrading Online	Support USB online upgrading function
	Resolution	Max. 1080P format
	HDMI	V1.4, 720P/1080P
	Scanning Format	Support 1080i Video crisscross DAS (Dynamic Adaptive Scan )
	Sound Control	Automatic sound standard detection, support for balance adjustment and surround Sound
	Sound Output	2X10W
Input and output ports	USB Multimedia Input ports	1-line
	Touchscreen port	1-line USB2.0
	HDMI Input port	2-line (HDMI1 keep for Inside OPS)
	VGA Input port	1-line
	PC Audio port	1-line
	Earphone Out	1-line
	Component Audio In	1-line
	RF Input port	3-line
	AV Input Output port	1-line
Standard Intel OPS Input and Output	USB Multimedia Input ports	2-line USB3.0
	Touchscreen port	1-line (Inside)
	HDMI Input port	1-line
	VGA Input port	1-line
	Audio port	1-line
	MIC Input	1-line
	IR Infrared Port	1-line
	RJ45 LAN	1-line
Touch parameters	Touch Technology	Infrared touch technology
	Touch mode	Single, multipoint,Mouse click
	Inductive objects	Finger,pen or any other opaque objects
	Inductive size	Diameter≥5mm
	Resolution	4096*4096
	Response time	1) First dot(click):8ms, continuously(writing):3ms 2) multipoint click:first dot(click):8ms,continuously(writing):8ms 3) Mouse click:first dot(click):8ms,continuously(writing):8ms
	Cursor speed	UP to 300 dots/s     Multipoint,mouse click:125 dot/s
	Operating life	≥60,000,000 times to click
	Power	USB power supply (4.6-5V, DC)
	Power consumption	≤1w
	Operation Systerm	Windows 8, windows 7, XP, Mac, Linux
	Calibration	HID devices standard, accord with Win7 multi-touch protocol, no need special software to calibrate, just use Table PC setting to finish the calibration.
	Anti-light decay function	Anti-light decay circuits to prevent the performance degradation caused by long working hours
	LED Test Software	Supply touch screen LED test software to test the function of each couple of the LED lights and the drawing functions
	Antilight interference function	can work properly in direct sunlight condition
Standard configuration	Interactive all-in-one touch monitor	1 set
	Remote Control	TV Remote control
	USB cable	1.5m USB cable for touch monitor, USB2.0 (Without PC option)
	HDMI cable	1.5m HDMI cable (Without PC option)
	VGA cable	1.5m VGA cable (Without PC option)
	Audio cable	1.5m audio cable (Without PC option)
	CD with Software	1 pcs
	Pens without ink	2 pcs
	User manul	1 pcs
Optional Configuration	PC (Optional)
		Version 1(Standard PC)
	Motherboard	Intel NM70
	CPU	Intel 1037U  1.80GHz
	RAM	DDR II 2G
	Hard Disk	500G
		Version 2 (Medium configuration PC)
	Motherboard	Intel Hm76
	CPU	Intel i3-3227U
	RAM	DDR II 4G
	Hard Disk	500G
		Version 3 (High configuration PC)
	Motherboard	Intel Hm77
	CPU	Intel i5-3337U
	RAM	DDR II 4G
	Hard Disk	500G
	Wireless Mouse	Optional
	Install Accessories
	Wall brackets	Optional


Product Overviews

Packaging & Shipping

Package : 1 Set / carton ( carton Inside +wooden carton outside )
Delivery time: 4-10 working days after the payment

Our Services
1.We supply Education Software for free if you buy the Touch screen monitor or Interactive Whiteboard from Riotouch.

2. We will supply Software OEM Service for our VIP customer (The customer who order above 100pcs whiteboard or 20pcs touch monitor could be our VIP customers)
3.Cheaper Price with high quality products.

4.Fast delivery and excellent sale and after-sale service

5.3 years warranty of touch frame is guaranteed

 FAQ

1.        Q:  What's the warranty and service?

           A: We provide OEM and ODM service and customized service,3 years warranty for SKD,1 year warranty for others

2.        Q:  How to assemble and use the products?

            A:  Please check the user's manual for reference

3.        Q: Whether to provide any teaching software?

            A: Yes, we provide free education software

4          Q: How to make the order?

             A: Send detailed inquiry to us, then we will reply you with the Proforma Invioce. Make the payment after you confirm the PI. We ship out the products by express or by sea within 4-7 days after we receive the payment. Then you will get the cargos soon.
