| Prod Model: |
TM01P32BG |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Semi Outdoor AD Player |
| Screen Size: |
30-40 Inches |
| Installation: |
Wall-Mounted |
| Type: |
Network Version AD Player |
| Screen Technology: |
LED |
| Interface Type: |
USB |
| Remote Control: |
With Remote Control |
| OS: |
Android |
| Customized: |
Customized |
Product Description
Main features:
| Remote control: | Full function infrared remote control. |
| Full HD display: | 1080P decoding, full HD LCD screen with LED backlit |
| Playlist editor: | Media contents can play by playlist mode or looping mode. |
| Advanced functions: | Support play log, customer logo |
| video/picture rotation: | 90/180/270 degree. (vertical display or horizontal display) |
| Min volume: | You can set min volume, for example level 18, then operator in retail shop
can't turn down volume lower than 18. |
| Timing function: | Set time power on /off and automatically display and loop,7days and 24
hours no manual operation. |
| Protection plate | Files on CF/SD card can be protected by protection plate from alteration
in mischief. |
| Multi-language OSD: | English.. |
| Two speakers: | Built-in stereo speakers (2x5W). |
| Files update: | Update media files automatically from inserted USB pen drive, no need
to pull out SD/CF card to download the files through computer. |
| Motion sensor: | Our unit will auto playback when detecting viewer, and will auto stop/mute/power
off when after viewer left in certain time; Or play all media files one time
and then power off. (Optional). |
| Rolling caption: | With the running marquee function (roll caption, text bar). |
| Display: | Support vertical or horizontal display |
| Network: | LAN,WiFi,3G netwok (option) |
| Support memory size : | 1GB-8GB |
| Accessories: | Use Manual, Power adapter, Remote Control |
More specs:
| LCD screen specs | Model number: | MW-2153MSP |
| Screen size: | 21.5" |
| Display proportion: | 16:9 |
| Resolution(Pixel): | 1920*1080 |
| Display color: | 16.7 M |
| Response time : | 8 ms |
| Luminance: | 350 cd/m2(Higher brightness optional) |
| Contrast ratio: | 800:1 |
| View angel (L/R/U/D): | 85/85/80/80 |
| Backlit: | LED |
| Media Formats | Video: | RM, RMVB, MKV, MOV , MPG, FLV,TS, AVI, , MP4(1080P decoding) |
| Audio: | MP3, WMA, |
| Picture: | JPEG, BMP,GIF,PNG |
| Power supply | AC Input: | 110-240V |
| Power consumption: | 60W |
| Appearance | Color option: | Black or optional |
| Housing material: | Whole metal housing
(front tempered glass/acrylic panel optional) |
| I/O interface: | 1*USB,1*CF card slot,1*SD SD/MMC/MS card slot, HDMI input |
| Installation: | Wall-mounting |
| Unit dimensions: |
|
| Active display area: | 477.417 (H) x 268.416 (V) |
| Product weight: | 10KGS |
Quotation:
Fob Shenzhen Non-network 220USD/SET,network 320USD/SET.
Trade conditions:
1. Payment Terms: We support most of ways for our transaction, such as T/T, L/C, D/A, D/P, Western Union,
MoneyGram....etc.
2. Production leadtime: 5-10days according to the order quantity.
3. Sample leadtime: 1days when there is stock, 5-10days for custom design.
4. Shipping Port: Shenzhen,China. We can manage shippment from the beginning to the end for you.
5. Door to door service: We have good channels by DHL/UPS/FEDEX/TNT as options for you.
6. MOQ: 1pc, sample order are welcome for your evaluation.
Quality guarantee:
1. All our products have one year guarrantee from the shipping date.
And it is ok upgrade to two or three years guarrantee with addtional cost.
2. Under guarantee: if any non-human damage happen, we'll offer free repairing or replacement, including delivery cost.
3. Out of guarantee: we offer repairing parts at lower cost, and service free in charge.
Custom design is welcome :
We accepted customized projects including software and hardware.
Do not hesitate to share your idea with us, since we have experienced engineer team and we always do our best to help client's project.
Shenzhen Tonme Technology Co., Ltd was established in 2011 and specialized in digital signages and LCD advertising player. We can customize 15 inch to 82 inch LCD display, CCTV LCD monitors, Digital signage, All-in-one PC, Touch screen displays according to customer's requirements.
We have maintained close partnership with world-class LCD manufacturer and world-class IC manufacturer. They can offer us the fastest and most reasonable price and technical support.
Our LCD Display solutions have been widely used in various industries, from Hotel, Supermarket, Retail, Entertainment, Advertising, Bus, Metro to many others.
We devote ourselves to quality, technology and service to provide perfect before sales, sales and after sales service. In order to meet the demand of market, we devote to new product development; We firmly believe because of our constant innovation, we can keep our strength and bring more new products to meet customers' requirements.
Welcome you esteemed partners to visit us and start business with us together.
