| Prod Model: |
ZYM |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Performance: |
Efficient Filtration |
| Structure: |
Mobile |
| Mechanical Principle: |
Vacuum |
| Type: |
Suction Filter |
| Usage: |
Oil and Gas Separation, Transformer Oil |
| Condition: |
New |
| Working Pressure: |
0.4MPa |
| Power(W): |
12.5kw |
| Application: |
Insulation Oil |
| Voltage: |
380V( as Needed) |
| Folw Rate: |
360-18000L/H |
Product Description
ZYM Mobile type Insulating Oil fltering Purifier
Specifications
Transformer oil purification device
1. Move to any working place
2. Dirty oil renewable, waste oil management
3. No pollution
Application:
According to fieldwork requirement, this machine equips the car wheels, which can be easy to move to any work point by traction. It is special suitable for purifying the transformer oil which locate in different fields. This machine can recover the seriously transformer oil. The treated transformer oil can reuse again in transformer.
Features:
1. Mobile (trailer) type, completely closed structure, waterproof, dustproof, move easy.
2. Installation of car tyres, Bridge shock absorber, braking system and steel welding of entire trailer guarantee 60km/h speed.
3. Dealing with unqualified insulating oils, rapidly remove water, gas, particles from oil
4. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies
5. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
6. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
7. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
Advantages:
Moble(trailer) type,completely closed structure,waterproof,dustproof,it can move long distance working in field.The importance of good quality power makes it very important that all the equipments give their best performance.
Technical Parameters:
Parameters |
Unit |
ZYM-6 |
ZYM-10 |
ZYM-20 |
ZYM-30 |
ZYM-50 |
ZYM-100 |
ZYM-150 |
ZYM-200 |
ZYM-300 |
Flow rate |
L/h |
360 |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
Vacuum degree |
MPa |
-0.06~-0.095 |
Working pressure |
MPa |
≤0.3 |
≤0.4 |
≤0.4 |
≤0.4 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
Temperature range |
°C |
20 ~ 80 |
Continuous working |
H |
150 |
Power supply |
|
Three phase,50HZ ,380V(or as per customer requirement) |
Working noise |
dB(A) |
60 |
61 |
63 |
70 |
70 |
75 |
70 |
70 |
70 |
Heating power |
kW |
9 |
11 |
13 |
15 |
30 |
48 |
58 |
70 |
85 |
Total power |
kW |
9.7 |
12.5 |
14.5 |
16.5 |
33.5 |
53 |
65 |
76 |
94 |
Oil inlet/outlet |
mm |
φ20 |
25 |
φ25 |
φ25 |
φ32 |
φ42 |
φ50 |
φ50 |
φ60 |
Weight |
Kg |
150 |
230 |
250 |
270 |
300 |
500 |
700 |
900 |
1100 |
Size |
L |
mm |
970 |
1050 |
1100 |
1150 |
1200 |
1600 |
1600 |
1800 |
1900 |
W |
mm |
630 |
750 |
850 |
900 |
950 |
1000 |
1100 |
1200 |
1200 |
H |
mm |
900 |
1300 |
1400 |
1450 |
1500 |
1800 |
1800 |
1900 |
1900 |
Guarantee Value:
Item |
Guarantee indexes |
Moisture content |
≤5 PPM |
Impurity size |
≤1 micron |
Gas content |
≤0.1% |
Breakdown voltage |
≥70 |
Trustable technical and after sale serivece
1. Long-term warranty of 2 years.
2. Provide best spare parts at low price (some for free).
3. Provide timely reply and technical support.
4. If anything wrong with the equipment, we would give prompt response and provide solution within 24 hours.
5. If there is technological innovation, we would guide our customer to upgrade.
