| Prod Model: |
MID188 |
| Panle: |
3.2 |
| Technology: |
Dual-band |
| Style: |
Smart Mobile Phone |
| Rear Camera Pixel: |
2MP-3MP |
| Display Color: |
16000k Color |
| Design: |
Bar |
| Operation System: |
Windows CE |
Product Description
Function
Processor
Samsung's S3C6410X RISC Microprocessor with ARM1176JZF-S based CPU subsystem. 667MHz
Memory&Flash
RAM: Mobile SDRAM 128MB upgrade 2GB
Flash: NAND Flash 128MB upgrade 1GB
OS
Windows CE 6.0
Language Support
More than 20 languages
Display
3.2 inch TFT LCD Panel + Touch: 320*240
Camera Sensor
1. Sub sensor: 300K/1.3M/2M Pixels(option)
2. Main sensor: 300K/1.3M/2M Pixels(option)
G-Sensor
BOSCH(Option)
Light Sensor
(Option)
Wolfson WM8753
System
Audio Codec
Earphone out/Mic built-in/Speaker *2
GPS function
YES(Option)
WiFi function
YES(802.11b/g)
Bluetooth function
YES(Bluetooth 2.0 )
MT6226+MT6139 (MTK Solution)
RF Device
GSM Function
Support four band: 850/900/180/1900
Battery PACK
Battery Type
Li-Lion battery 3.7V(TDB)
SD Card Slot
T-Flash(Up to 8G)
SIM Card Slot
Two SIM card
USB I/O Port
USB I/O 13Pin
ME Connector
Battery Connector
3pin connector
Speaker
Speaker 8Ω (1.0W) *2
Internal MIC
Non_direction MIC *1
Vibrator
Vibrator *1
RF Antenna
WiFi&BT*1 GPS*1 GSM *1
Other
Key
VOL up/VOL down/capture key/reset key
Connect me!
All In One Electronic & Communication is dedicated to the mobile terminals 's research and development of GSM2.5G/3G, from Industrial Design (ID), Mechanical Design (MD), User Interface design (UI), Hardware design (HW), Software design (SW), Manufacturing (Manufacturing), Test (Testing), Quality Assurance (QA), It's the perfect solution for mobile terminals!
