Product Description
1. Universal information:
| Place of Origin: | Shenzhen China |
| Brand Name: | GPI |
| Model Number: | GPI-FC-001 |
| Certification: | ISO9001:2008, SGS,Rohs |
2. Business Terms:
| Minimum Order Quantity: | 50 pieces |
| Price: | USD 0.6~15 |
| Packaging Details: | Inner packing:1pc/PP bag,PE bag,gift box Outer packing: exporter standard carton, or according to customer request |
| Sample Delivery Time: | Around business days after deposit received |
| Production Delivery time | 9-14 working days after PO confirming. |
| Payment Method: | T/T/ western union/ paypal or L/C |
| Payment Terms: | Sample and tooling:100% payment before order
Msss Production:30% downpayment,70% balance before shipment |
| Supply Ability: | | 100,000 Piece/Pieces per Month |
|
2. Description:
Flex Flat cable:
1) Flex flat cable, double or single layer
2) Gold plated finger, immersion gold, tin plated(all plating with Lead free)
3) Resistance circuit available
4) Capacity circuit available
5) Anti electromagnetic interference
6) SMT for components available
7) 0.5 to 1.25mm Pitch as request
8) PI stiffener available.
9) Rohs , SGS standard
10) ISO9001:2008 passed enterprise.
Expert in mobile phone FPC, Dome switch, light touch switch, light guide switch, camera FPC assembly, various connect cables.
3. Our Advantage:
1) Group Financial support
2) Strong R&D capability
3) Low cost and competitive price
4) Quick delivery
5) 100% computer test and inspection before shipment
6) One stop purchase available for customer
7) Whole solution design available
8) All Products provide one year quality warranty
4. Applications:
*Medical Equipment
* Telecommunications apparatus
* Smart phone systems
* Household appliances
* Security systems
* Various industry control keypad panel
5. Specification:
| Layers Qty | 1 - 6 layers | | nished FPC Size | Min.:4x4mm Max.:250x1200mm | | FPC Board Thickness: | 0.08-0.12mm for single layer, 0.12-0.22mm for double layer | | Stiffener Material Choice | PI.PET,FR4-PI | | Pitch of the Pin | 0.3mm, 0.5mm,0.8mm,1.0mm, 1.25mm,2.54mm | | Finished Board Thickness Tolerance | ±0.03mm | | Finished hole diameter(Min.) | 0.15mm | | Finished hole diameter(Max) | 0.6mm | | NPTH Hole diameter tolerance | ±0.025mm | | PTH hole diameter tolerance | ±0.050mm | | Copper foil thickness | 18um,35um,70um/ | | Circuit width/spacing(Min.) | ≥0.065mm(1/2oz)≥0.05mm(1/3oz) | | Surface Finished type | OSP. Gold plating, Immersion Gold, Tin plating(lead free)etc | | Gold Flash Ni/Au thickness | Ni:2.54-9um Au:0.025-0.5um | | Immersion Tin thickness | 0.7-1.2um | | Tin plating thickness | 3-15um | | Drill hole position tolerance | ±0.05mm | | Punching dimension tolerance | ±0.05mm | | Certificate | ROHS,UL,ISO9001 etc |
FPC Manufacturing Capability Technical Performance Data |
6. 1. Technical Data:
| Layers Qty | 1 - 6 layers | | nished FPC Size | Min.:4x4mm Max.:250x1200mm | | FPC Board Thickness: | 0.08-0.12mm for single layer, 0.12-0.22mm for double layer | | Stiffener Material Choice | PI.PET,FR4-PI | | Pitch of the Pin | 0.3mm, 0.5mm,0.8mm,1.0mm, 1.25mm,2.54mm | | Finished Board Thickness Tolerance | ±0.03mm | | Finished hole diameter(Min.) | 0.15mm | | Finished hole diameter(Max) | 0.6mm | | NPTH Hole diameter tolerance | ±0.025mm | | PTH hole diameter tolerance | ±0.050mm | | Copper foil thickness | 18um,35um,70um/ | | Circuit width/spacing(Min.) | ≥0.065mm(1/2oz)≥0.05mm(1/3oz) | | Surface Finished type | OSP. Gold plating, Immersion Gold, Tin plating(lead free)etc | | Gold Flash Ni/Au thickness | Ni:2.54-9um Au:0.025-0.5um | | Immersion Tin thickness | 0.7-1.2um | | Tin plating thickness | 3-15um | | Drill hole position tolerance | ±0.05mm | | Punching dimension tolerance | ±0.05mm | | Certificate | ROHS,UL,ISO9001 etc |
FPC Manufacturing Capability Technical Performance Data |
|
| Product category | Flexible or combined with Rigid PCB board |
| Monthly output | 5000 square meters. |
| Material | Polymide, Polyster, PET,PT,Rolling,Electrolysis |
| File format | CAD file(POWERPCB,PROTEL,PADS2000,AUTOCAD,ORCAD, Gerber file |
| Solder resist (solder mask) | Laminated cover film,Liquid photosensitive prevent weld ink,PI oil film |
| Surface treatment | Hot Air Solder Leveling,Tinning ,Sink tin ,gold-plating ,Chemistry sink gold ,Anti-oxidation ,Sink copper ,Tin copper |
| Finished Thickness | 0.068-0.6mm |
| Circuit Layers | Single-sided/multi-layer(4-2 Layer) |
| Max thin wire/spacing | 2-3mil |
| Min Hole Diameter | 0.2mm |
| Maximum thickness/aperture ratio | ≤5Max Outline |
| Max Outline | 500×350mm |
| Profiling Process | 0.1mm CNC punching accuracy 0.1 mm edge |
| Acceptance Standard | Guest standard ,IPC, GB standard (China) |
| Sample Leadtime | 3 to 5 Days |
SZ Cmute Science & Technolodgy development Co., Ltd ( Group member of Ju xin ) is professional company which focus in manufacturing High-precision, High density and High reliable FPC & Membrane circuit and related PCB products, the company is located in DingFeng Science & Technolody park, NO. 3 Industrial zone, Luo Tian of Songgang Twon, Baoan District, Shenzhen, Which has convenient transportation.
The company's products are widely used in communication, Audio & Video Products, Digital products, Electronics, Car electronics, Smart control equipments, Micro-Motor, Therapy Products, Automatic office equipment and many fields.
Cmute has the modern standard and high clearance facility with over 6000 square meters, which equipped well with advanced automatic production equipments and high precision test instruments.
We are an ISO9001: 2008 certified company, we provide our customers with our high precision & top quality products, also our quick response and high efficiency services has won many praise from worldwide clients.
Our group also have polydome, metal dome and membrane switch and PCB assembly factories in Dongguan & Shenzhen, so we can provide our customers with one stop shopping with competitive price.
At present, We have successful cooperation with Philips, Coolpad, Gionee, Malata and many famous brands.
We'll continuously improve our quality and services, Cmute, your best partner!
