| Prod Model: |
MSR009 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation: |
External |
| Card Slots: |
All in 1 & Multi in 1 |
| Interface: |
USB |
Product Description
Data Collection/Intermittent Data Collection/Interrupted function/Battery rechargeable/Mini size:
MSRv009 is protable data collector, a portable magnetic swipe card reader, which is specially designed for magnetic stripe data collection anytime and anywhere without computer. Large memory can collectt 3200 data, Built-in Time clock indicates every transaction data and time. Data is read from the card and kept into the memory then downloaded to the computer.
Small interrupted reader
Interrupted function
Battery rechargeable
Mini size: 10*5.8*2.5mm
Specification:
PCB size: 10*5.8*2.5mm
Weight: 10. G
Memory: 2M Byte EEPROM
Power supply: Take Power by lithium battery, USB port and directly charging, maintaining 20 more days after fully charging.
Cards Standard: ANSI, ISO, ABA
Track: 1&2 tracks bidirectional readable
Data structure: Date + time +' %'1st track data? '+': 2ND track data '? ' 3rd track data?
Storage record: 8000 records for Permanently remain, they can be canceled or updated by command
Output interface: USB communication cable, command download, USB 2.0
Operating Temperature: -10 ~ 50 C
Relative Humidity: -20 %~ 70 %rh
Lifespan of magnetic head: 50 0000 times
Features:
- Ultra low power consumption
- Reads interrupted swipes in both directions
- Reads all magnetic cards
- Low voltage operation
- Swipe Direction - bidirectional
- Data downloadable to the computer via USB
- Time stamp shows date and time with every transaction
- Hardware imbedded password protection
- 3-track version can collect all three tracks data
- Fully encrypted
- Stores 32000 card scans
- All swipes are timestamped
- Data retained even if power is removed
- No programming required, easy to use as 1- 2- 3
Applications:
- Any movable data collection (Trade shows, Racing events)
- Point of sales
- Law enforcement (DMV card)
- Attendance (Student ID, Membership card)
- Conference Attendance
- Classroom Attendance
- Meeting Attendance
- Door Locking Systems
ISO Standard:
Track 1 210 bpi, 79 Alphanumeric Characters
Track 2 75 bpi, 40 Numeric characters
Track 3 210 bpi, 107 Numeric characters
Packing:
MSR009 Device
3mm 2 tracks maghead
USB Data Cable
USB Charger
Rechargeable Battery
Plastic Rail/ Magnetic Swipe Slot
Software
Mannual
