Mini Rapid Freezing / Chilling Machine

Prod Model:	Mini Rapid Freezing / Chilling Machine L10
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension:	800*815*1640mm
Inner Dimension:	600*420*870mm
Temperature:	From 70 to 3 Degree in 90 Minutes
Temperature 2:	From 70 to -18 Degree in 240 Minutes
Voltage:	220V/50Hz
Refrigerating Capacity:	4419W
Quality:	Durable and Energy-Efficient
Cooling System:	Air Cooling
Material:	Stainless Steel 304
Compressor:	Italy Embraco
Door Number:	Single Door
Door Type:	Swing Door
Power Source:	Electricity
Temperature Control:	Computer Thermostat
Temperature Type:	Single-temperature
Defrost Type:	Auto Defrost
Function:	Freezing
Certification:	RoHS
Capacity:	219L
Type:	Mini Rapid Freezing Machine

Product Description

Mini Rapid Freezing/Chilling Machine for Food

Mini quick freezer is made by Stainless steel 304,
using famous brand Italy Embraco compressor which is durable and energy-efficient

MODEL	L3	L5	L10	L14
Dimension: (W*D*H/mm)	800*815*925	800*815*1015	800*815*1640	800*815*2170
Inner Dimension: (W*D*H/mm)	600*420*330	600*420*400	600*420*870	600*420*1170
Temperature:from 70ºCto 3ºC  in 90minutes	12kg	18kg	40kg	55kg
Temperature:from 70ºC to -18ºC  in 240minutes	8kg	14kg	28kg	38kg
Power:(W)	984	1227	1750	2800
Refrigerating capacity: -10ºC/45ºC	2080	3104	4419	6222
Voltage:	220V/50HZ	220V/50HZ	220V/50HZ	220V/50HZ
		400V/3/50HZ	400V/3/50HZ	400V/3/50HZ
Defrost type	Hot gas	Hot gas	Hot gas	Hot gas
Quantity of trays:GN1/1/530*325*65mm	3units	5units	10units	14units
Quantity of  Stainless steel side disk:600*400*30mm	3units	5units	10units	14units
Weight		119kg

General Introduction:
The blast freezer is assembled with super freezing system which can help the center of the products to reach the scope of the user's requirement in order to prevent the bacterial growth to keep the original organization construction and the freshness of the stored food.  It is allocated with the Germany Bitzer compressor cooling system and Denmark Danfoss expansion valve, etc. The warranty period of the whole machine is 1 year.

Features:
1. The whole machine is controlled by the computer intelligent system with super huge LCD screen.
2.Dual working modes of time and temperature have nice performance of heat insulation.
3. Output is adopted the low noise and undisturbed technology.
4. Adoption of the entire high density foaming and total closed construction has perfect heat insulation function, saves the energy and protect the environment.
 5.Superior freezing ability prevent the ice crystal among the process of temperature fall period.
6..Adpoting the UFI approved environmental-friendly refrigerant R404A.
