| Prod Model: |
HEPO-B310 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 220V/50Hz: |
Shelves/ Baskets5/15 |
| 4±1degree: |
270kgs |
| Certification: |
SGS/GMP |
| Type: |
Temperature Controller |
| Usage: |
Refrigerator |
| Control Type: |
Digital |
| Display Type: |
LED |
| Material: |
Stainless Steel |
Product Description
Precise Temperature Control System
Famous microcomputer control system,4±1Degree,precise and steady,high brightness digital display,PT100 sensor.0.1Degree precise,0.1Degree distinguishability,0.1Degree adjust increment.Special high-resolution of temperature correction function for setting point,the adjust increment is 0.1Degree.
Intelligent control fan force cold air circle system to assure the temperature evenness inside the cabinet.
Refrigerating System
Hermetically Sealed CFC Free Famous Compressor.
Introduced Bi-Sonic double air blower,low temperature and moisture resistance.Germany EBM radiator blower.
CFC free ECO-friendly freezing medium.
Perfect Safety Control
Keyboard locking and password-protected function(Optional).
Operator's menu and supervisor's menu were dividing by special controlled parameters to keep the secret and safety(Optional).
Three alarm ways:buzzer siren,blinking display,distant signal alarm(Some are Optional):over/low temperature alarm,sensor failure alarm,door opening alarm,power-down alarm,fault point code alarm.
The alarm for temperature rang can be set freely.
Remote interface for distant signal alarm(Optional).
Self-checking of time delay starting,stoping interval protecting function.
72 hours electricity can be support by internal lithium ion battery for temperature display and alarms of buzzer sire/blinking display.
The situation of refrigerator on highest or lowest temperature can be recorded automatically.
History date memory recording function,and power-down memory recording function.
Special electricity-saving lamp for illumination in refrigerator.
Humanization design
Adopt the specialized stainless steel blood holder can be adjusted by you.
The large-screen design is easy for observation.
The safe lock design can prevent missing-opening.
Wide voltage band is available for 187-242V voltage.
The refrigerator body is made of high-quality structural steel plate, which is treated with advanced phosphate rot-proof spray coating processing. The surface color is soft.
Double transparent insulation glazed door, filled with inert gas.
The power saving lamps on the body can light the whole space inside the refrigerator.
The double high-transparent synthetic glass little-door can prevent large cold air from spilling when the door is opened.
Model | External Size
W*D*H/mm | Voltage | Temp | Climate type | Capacity | N.W. | Shelves/
Baskets |
| HEPO-B120 | 598*618*1110 | 220V/50HZ | 4±1 ºC | N | 120L | 65kgs | 2/4 |
| HEPO-B310 | 660*644*1960 | 220V/50HZ | 4±1 ºC | N | 310L | 270kgs | 5/15 |
| HEPO-B400 | 750*761*1799 | 220V/50HZ | 4±1 ºC | N | 400L | 130kgs | 5/20 |
| HEPO-B500 | 710*800*1975 | 220V/50HZ | 4±1 ºC | N | 500L | 126kgs | 6/18 |
