| Prod Model: |
RO lab |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
RO Lab |
| Feed Water: |
Tap Water |
| Pure Water Outlet: |
RO Water |
| Instant Flow Rate: |
>1.5 Liters/Min(Need Storage Tank) |
| Flow Rate: |
15 Liters/Hour* |
| Ionic Rejection: |
>95% |
| Organic Rejection: |
>99%(Molecular Weight>100) |
| Bacteria: |
<1cfu/Ml |
| Dimension/Weight: |
Lxwxh:41X22X42cm/About20kg |
| Power: |
220V,50-60Hz;48W |
| Style For Purifier: |
Table Top |
| Type For Purifier: |
Reverse Osmosis |
| Certification: |
CE |
| Water Temperature: |
Normal |
Product Description
The reverse osmosis technology produces RO water:
1)Aplication
Ultra-pure water fill the system, glass washing, agricultural experiment, and aquaculture
The ordinary biology experiment, constant temperature wet equipment, humidifier and autoclave optimizations water
2)Flow schematic PF+AC+RO+AC
LV. 1 Special spun fiber filter
LV. 2 Special active carbon filter
LV. 3 Special active carbon filter
LV. 4 100 GPD RO membrabe
LV. 5 Mixed bed resin cartridge
3)Fetures
Domestic exclusive a injection molding import plastic case, sanitation PP plastic material, appearance is delicate
Case can be rapidly unscrew cover, realize unpacking can quick change without advance, accord with GLP standard filter column
Automatic pressure sensor control work, RO film automatic antiscale flush, tap water off the water automatic stop
Water barrel automatic filling water, water bucket of water full automatic stop.
4)After-sales
· The products customers buy from our company enjoy repair service since the day of purchase. In on year from the purchasing day, our company is obliged to replace components free of charge due to non-human-behavior factors except:
(1). Damage caused by maloperation or use in abnormal situations.
(2). Disassembly any part of the machine or human-behavior damage.
(3). Not repaired by our serviceman.
As a rich experience of pure water system manufacturer, Hitech uphold the common development concept with customers, and provide professional pre-sales support and after-sales service. We promise:
12months for maintenance(except consumables).
On site installation supervision.
Free system update service.
Periodically return service.
Service hotline-400.
5)Main Market
Asia, The Middle East, Eastern Europe and South Africa
|
Specification |
RO system |
RO deionized system |
|
Model |
RO lab |
RO lab plus |
RO DI/RO DI digital |
RO DI plus/RO DI digital plus |
|
Flow procedure |
PF+AC+RO+AC |
PF+AC+RO+AC |
PF+AC+RO+DI |
PF+AC+RO+DI |
|
Application |
Ware washing, Agricultural expe, General biological expe, Aquatic products feeding, Inlet water for Ultra pure water machine, Inlet water for sterilizer/T&H chamber |
Buffer disposing, Physical and chemical analysis, Fine chemistry industry, GC/HPLC, Inlet water for Ultra pure water machine, Aseptic drinking water |
|
Feed water requirement |
Tap water: TDS<200ppm,5-45ºC,1.0-4.0Kgf/cm 2
(if inlet TDS>200ppm, extra pretreatment is recommended) |
|
Purification system |
Pretreatment unit |
Special spun fiber filter×1+Special active carbon block filter×1+Special active carbon block filter×1 |
|
RO unit |
100GPD RO membrane×1 |
100GPD RO membrane×2 |
100GPD RO membrane×1 |
100GPD RO membrane×2 |
|
Subsequent unit |
Post active carbon filter×1 |
Mixed bed resin cartridge×2 |
Mixed bed resin cartridge×3 |
Pure water
quality |
Desalination rate% |
>95% |
>95% |
|
TDS |
5-10 ppm* |
RO water:5-10 ppm* |
|
Resistivity |
- |
15-18.2MΩ.cm |
|
Conductivity |
- |
0.067-0.055µs/cm |
|
Output(25ºC ) |
15 liters/hour* |
30 liters/hour* |
15 liters/hour* |
30 liters/hour* |
|
Flow rate |
2 liters/min(with pressure tank) |
|
Pure water outlet |
RO water |
RO water, deionized water |
|
Control system |
Automatic electronic pressure sensor controlling, RO membrane auto flushing, automatic stop without water, automatic stop when water tank full, automatic cutting off water when pump stopping, guaranteeing 24 hours' work. |
|
Water quality monitor |
TDS test pen |
TDS test pen +on-line resistivity monitor |
|
Electric requirements |
AC110-220V,50/60Hz, 48W plus model:72W |
|
Dimension and weight |
Length×Width×Height:41×22×42cm / 12-14kg |
|
Standard configuration |
Main body(including:1 set cartridge)+4.0 gallon water tank + TDS pen + accessory box |
