Lower Power Consumption of High Vacuum Transformer Insulating Oil Purifier

Prod Model:	J Y- D F S30
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Working Pressure:	0.2~0.35 MPa
Temperature:	-10~70 Centigrade
Flow Rate:	30 Stere/H
Filtration Precision:	2,5,10,15,25 Micrometer(Optional)
Anti-Hazard Classification:	Grade 2
Dimension:	2200*1500*2350mm
Weight:	965 Kg
Filter Element Quantity:	200pieces
Structure:	Polymer Membrane
Type:	Membrane Filter

Product Description

Product Introduction:

Excellent Performance:
<>Polymer membrane filtration technology
<>Oil-water separation efficiency is more than 95%
<>Breaking the emulsified structure, and free water after filtration is less than 100 ppm
<>Capacity 200 tons daily and supply oil purification on working site
<>380V anti-explosion electric motor with continuous working pattern
<>High precision can be controlled within 2~25 micron
<>Deep filtration from 3~16 mm and can be used as by-pass filter
<>Selectivity-pass characteristic of 3D pore structure filter elements
<>Acid and alkali resistance of polymer membrane material
<>High interception rate and low filtration cost
<>Small operating space and convenient drain valve
<>Quick open head cover, easy to maintain
<>Customized service provided according to filtration requirements
<>Made of high quality thick steel plate, anti-corrosion treatment
<>Stainless steel tank pass pressure test can be customized
<>Filter elements can be used repeatedly after back-washed
<>Design service life is more than 20 years (except for filter elements)

Technical Parameters:
1.Model Type: JY-DFS30
2.Flow Rate: 30 m³/h
3.Filtration System:
(1)Filter Elements
Membrane Filter Element------------------------------------------J30-980H
Separation Filter Element------------------------------------------F150-800
Coalescence Filter Element---------------------------------------R150-800
(2)Filter Element Quantity: 200 Pieces
(3)Function: Remove impurity particles, colloid and emulsified water
(4)Working Pressure: 0.2~0.35 Mpa
(5)Filtration Level: 3
(6)Service life: 2~3 Years or longer
4.Filtration Precision:
(1)Range: 2,5,10,15,25 μm
(2)Standard: 5~10 μm
5.Security:
With Pressure Safety Valve and Air Release Valve
6.Temperature:
Working Temperature: -10~70 ºC
8. Dimension: 2200*1500*2350mm
9.Weight: 965KG
10.Anti-hazard Classification: Grade 2

Proprietary Technology:

Polymer Membrane Filter Element:



Oil flows through the Jingyuan polymer membrane filter elements, pass a 3D pore structure which the pore precision can be controlled in 30~0.2μm. And by back washing or back blowing the blocked pore, filter elements can be used repeatedly, about 2~3 years or longer.


Various Products Solves Your Problem in Oil Purification :
Large Capacity High Precision Diesel Refined Machine:JY-DF Series
Small Volume Diesel Purification Strainer:JY-219 Series, JY-T Series
Portable Industrial Oil Filtration Trolley:JY-E Series, JY-M Series
Diesel Demulsification Filtration System:JY-DFF Series
Sea Oil Water Removal System:JY-DFS Series
High Viscosity Hydraulic Oil/Gear Oil/Engine Oil Purification Refined Machine:JY-G Series, JY-H Series

Principle:
Selectivity pass characteristic is to say, the oil molecules will pass and water molecules or impurities will be intercepted, so that the oil and water can be separated.

Large Capacity Diesel Purification Filter Technical  Parameters
Item		Unit	JY-DF15	JY-DF15A	JY-DF15A+	JY-DF60A	JY-DF60	JY-DF60B
Flow Rate		m³/h	15			60
Filter Element Quantity		Piece	100		200	371
Filter Element Type			J30-970H			J30-990H		J30-990H F150-800
Filtration Stage		Level	1					3
Dimension	L	mm	800	1460	1600	1230	1230	2000
	W	mm	700	805	1200	1650	1150	1400
	H	mm	2000	2030	2010	2200	2200	2350
Weight		KG	210	360	560	893	632	1130
Power System	Voltage	V		380 Anti-explosion Grade 2
	Pump			Diesel Centrifugal Pump
End Flange			DN65~80	DN80~100	DN80~125	DN80~125
Security			With Pressure Safety Valve
Function			Remove impurity particles, colloid and water
Working Pressure		Mpa Psi	0.2~0.35 29~51
Service Life		Year	2~3
Filtration Precision		μm Mesh No.	2,5,10,15,20,25 6250,2500,1250,800,625,500
Working Temperature		ºC	-10~70
Suitable Oil			Light Diesel,Diesel Fuel
Application Field			Diesel Refinery, Oil Depot, Oil Storage Tank, Concrete Mixing Station, Transportation Company, Railway Locomotive Gas Station, Fishery Industry

Mobile Industrial Oil Filtration Trolley Technical Parameters
Item		Unit	JY-M50	JY-E50	JY-DM50
Flow Rate		L/min	40
Filter Element Quantity		Piece	68
Filter Element Type			J22-401L/H		J22-405L/H
Filtration Stage		Level	2
Dimension	L	mm	550		700
	W	mm	560		650
	H	mm	920		1000
Weight		KG	77		100
Power System	Voltage	V	380/220	HONDA 5.5HP	220
	Pump		Gear Pump		Diesel Centrifugal Pump
End Flange			DN20
Security			With Pressure Safety Valve
Function			Remove impurity particles, colloid and water
Working Pressure		Mpa Psi	0.2~0.35 29~51
Service Life		Year	2~3
Filtration Precision		μm Mesh No.	2,5,10,15,20,25 6250,2500,1250,800,625,500
Working Temperature		ºC	-10~70
Suitable Oil			Diesel, Lube Oil, Hydraulic Oil,Gear Oil, Engine Oil
Application Field			All Kinds of Diesel Vehicles, such as SUV, Jeep, Business Car, Bus, Engineering Machinery, Mining Machinery, Agricultural Machinery, Generator Unit

Industrial Oil Demulsification and Filtration Machine Technical  Parameters
Item		Unit	JY-DFS30	JY-DFF60	JY-C500-20	JY-C500-40	JY-G100	JY-G200	JY-H130	JY-H330
Flow Rate		m³/h L/min	30m³/h	60m³/h	20m³/h		32,40,63 L/min		30~40L/min
Filter Element Quantity		Piece	200				36
Filter Element Type			J30-980H F150-800 R150-800	J30-990L F150-1000 R150-1000	J30-980H F150-800 R150-800		J30-970H	J30-970H F150-500 R150-500
Filtration Stage		Level	3				1		4
Dimension	L	mm	2200				800		450	1160
	W	mm	1500				750		700	450
	H	mm	2350				1350		890	1000
Weight		KG	965				115		45	148
Power System	Voltage	V	380/220/DC24/DC12
	Pump		Diesel Centrifugal Pump
End Flange			DN80~125				DN20~40
Security			With Pressure Safety Valve and Air Release Valve
Function			Demulsification and Impurity Particles, Colloid, Water Removal
Working Pressure		Mpa Psi	0.2~0.35 29~51
Service Life		Year	2~3
Filtration Precision		μm Mesh No.	2,5,10,15,20,25 6250,2500,1250,800,625,500
Working Temperature		ºC	-10~70
Suitable Oil			Sea Oil, Emulsified and High Viscosity Industrial Oil,  Including Diesel, Hydraulic Oil,Engine Oil, Gear Oil and Lube Oil
Application Field			Mining Machinery, Engineering Machinery, Construction Machinery, Power Generator Unit, Gas Station, Oil Depot, Oil Storage Tank

Small Volume Fuel Purification Filter Technical  Parameters
Item		Unit	JY-219	JY-219A	JY-T32A	JY-T32	JY-T100
Flow Rate		L/min	40				60
Filter Element Quantity		Piece	34		68		90
Filter Element Type			J30-970H		J22-400L/H		J22-330L/H
Filtration Stage		Level	1		2		3
Dimension	L	mm	310	310	680	660	1370
	W	mm	300	390	480	350	410
	H	mm	650	670	660	650	830
Weight		KG	21	30	64	49	125
Power Syetem	Voltage	V		380/220/DC24/DC12
	Pump			Diesel Centrifugal Pump
End Flange			DN20				DN65
Security			With Pressure Safety Valve
Function			Remove impurity particles, colloid and water
Working Pressure		Mpa Psi	0.2~0.35 29~51
Service Life		Year	2~3
Filtration Precision		μm Mesh No.	2,5,10,15,20,25 6250,2500,1250,800,625,500
Working Temperature		ºC	-10~70
Applicative Oil			Light Diesel, Industrial Oil
Application Field			Mining Machinery, Engineering Machinery, Construction Machinery, Power Generator Unit, Gas Station, Oil Depot, Oil Storage Tank

Application:
Large oil depot, gas station and other diesel storage tank:
Filters were widely being used in domestic. But due to vehicle transportation during diesel fuel storage in large oil depot , certain pollution were exist. In addition, because of oxidation and water absorption of diesel, there are a large amount of sludge and water deposited at the bottom of tank. As a result, diesel filters were installed at these oil tank area to ensure the diesel purity. It's the same in foreign countries.
