| Prod Model: |
JJL |
| Product: |
Low Pressure Solar Water Heater with Feeding Tank |
| Inner Tank Material: |
SUS304,SUS316,0.4mm,0.5mm,0.6mm |
| Outer Tank Material: |
Galvanized/Color Steel,Powder Coated,Stainless |
| Accessories For Opition: |
Assistant Tank,Magnesium Rod,Solar Controller |
| Tank Capacity Opition: |
100L,120L,150L,180L,200L,250L,300L,360L |
| Solar Stand/Bracket/Support Material: |
Solar Stand/Bracket/Support Material |
| Application: |
Solar Water Heater,Solar Collector,Solar System |
| Max. Capacity: |
>200L |
| Structure: |
Compact Type |
| Pressure: |
Unpressurized |
| Interior Material: |
Stainless Steel |
| Collector Components: |
Glass Vacuum Tube |
| Composition: |
Collector |
| Certification: |
CCC |
Product Description
Low Pressure Solar Water Heater With Feeding Tank
We manufacturer of solar water heater more then 15years in China.
Main products:non pressure solar water heater,high pressure solar water heater,prea-heated solar water heater,heat exchange solar water heater,heat pipe solar collector,non pressure solar collector,solar manifold,split solar water system etc.
Specification:
1.Inner tank:SUS304-2B 0.4mm/0.5mm/0.6mm
2.Outer tank:Galvanized SteelSUS304-0.4mm
3.Insulation layer:50mm
4.Bracket:Galvanized Steel 1.5mm
5.Vacuum Tube:58x1800mm
Model | Tube Size | Absorber Space | Volume | Tube Qty | Actual Capacity | Loading QTY |
| | MM | M2 | M3 | | (L) | 20' GP | 40' GP | 40' HQ |
| JIJ4715-15-NP | 47*1500 | 1.69 | 0.36 | 15 | 82.5 | 72 | 150 | 188 |
| JIJ4715-18-NP | 47*1500 | 2.03 | 0.42 | 18 | 99 | 61 | 128 | 161 |
| JIJ4715-20-NP | 47*1500 | 2.25 | 0.46 | 20 | 110 | 56 | 117 | 147 |
| JIJ4715-24-NP | 47*1500 | 2.70 | 0.54 | 24 | 132 | 48 | 100 | 125 |
| JIJ4715-30-NP | 47*1500 | 3.38 | 0.65 | 30 | 165 | 40 | 83 | 104 |
| JIJ5818-15-NP | 58*1800 | 1.92 | 0.59 | 15 | 120 | 44 | 91 | 115 |
| JIJ5818-18-NP | 58*1800 | 2.31 | 0.69 | 18 | 144 | 37 | 78 | 98 |
| JIJ5818-20-NP | 58*1800 | 2.57 | 0.74 | 20 | 160 | 35 | 72 | 91 |
| JIJ5818-24-NP | 58*1800 | 3.1 | 0.89 | 24 | 192 | 29 | 60 | 76 |
| JIJ5818-30-NP | 58*1800 | 3.62 | 1.09 | 30 | 240 | 23 | 49 | 62 |
| JIJ5818-36-NP | 58*1800 | 3.89 | 1.29 | 36 | 288 | 20 | 41 | 52 |
