| Prod Model: |
Master-R UVF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Source Water: |
Pure Water |
| Outlet: |
RO Water, up Water |
| System Output: |
10litres/Hour* |
| Heavy Metal Ion(Ppb): |
<0.1ppb |
| Total Organic Carbon(Toc): |
<3ppb |
| Endotoxin: |
<0.001EU/Ml |
| Microbe: |
<1cfu/Ml |
| Dimension: |
Lxwxh:50X36X54cm/ About22kg |
| Power: |
100-250V, 50Hz/120W |
| Certification: |
CE |
Product Description
1)Application
HPLC, IC, ICP-MS, CF-AAS, Physics, electrochemical and interface research, molecular biology and life science,
Animal cells and plant cell culture
2)Technique data
Model Master-R UVF
System output(25° C): 10litres/hour*
Instant outout: >1.5litres/min(need pressure storage barrel)
Resistivity: 18.2MΩ -cm@25° C
Heavy metal ion(ppb): <0.1ppb
Total organic carbon(TOC):
Endotoxin: <0.001EU/ml
Microbe: <1CFU/ml
Granule(>0.22μ M): <1/ml
RO water TDS(ppm): <10*
Outlet: 2 piece: RO water, UP water
Dimension: LengthXWidthXHeight: 50X36X54cm/ about22Kg
Power: 220V, 50Hz/120W
3)Flow schematic PF+KDF+AC+RO+RO+UV+AC+DI+UF+TF
LV. 1 10' spu fiber filter
LV. 2 10' mixed KDF filter
LV. 3 10' active carbon block filter
LV. 4 100GPD RO membrane
LV. 5 Double (254&185nm) wavelength UV lamp
LV. 6 Post active carbon filter
LV. 7 Ultra pure polishing resin cartridge
LV. 8 MWCO 5000D UF eliminating endotoxin cartridge
LV. 9 (0.45+0.1)μ M importing PES terminal filter
4)Perfomance characteristics
Automatic micro-computer system, multi-menu operating,
Super-large LCD display, the resolution is 240*128, animation mode display.
3 road on-line water monitoring, monitor the inlet water, RO water and ultra purification water quality
Automatic RO membrane antiscale flush program, prolong RO membrane life-span
Fault automatic detection, provide security guarantees
The system setting are protected by the password, prevent unauthorized change
Can set pretreament, RO membrane, UV lights and ultra purified column life, show the with and remaining life of consumables
Various specifications storage barrels can be selected to meet diffierent needs
Integration plastic molding chassis, human body engineering design, accor with GLP standard
The KDF filter column can acheive 1 year without replacement, operation cost reduction.
The U. S. DOW DOW or fluid FCS produced, realized the the combination of RO membrane long life with high quality water.
The original import nuclear level resin, always guarantee top water quality
Double (185nm&254nm) importing UV cartridge
The original importing PES MWCO 5000D UF ultra filter cartridge
0.45+0.1µ Mimport PES polyether sulphone composite membrane filter terminal aseptic filter, assuring water quality aseptic
Standard congfiguation Host(1 set of pure polishing resin cartridge))+15 litres storage barrel+accessory bag
5)After-sales
· The products customers buy from our company enjoy repair service since the day of purchase. In on year from the purchasing day, our company is obliged to replace components free of charge due to non-human-behavior factors except:
(1). Damage caused by maloperation or use in abnormal situations.
(2). Disassembly any part of the machine or human-behavior damage.
(3). Not repaired by our serviceman.
6)Main Market
Asia, The Middle East, Eastern Europe and South Africa
