| Prod Model: |
PA |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| For Sodium Lamp/Metal Halide: |
70W 150W 250W 400W |
| Type: |
Aluminum Electrolytic Capacitor |
| Application: |
High Voltage |
| Package Type: |
Surface Mount |
| Capacitance: |
1-50uf |
Product Description
Lighting capacitor for high pressure sodium lamp, fixed capacitor for metal halide lamp. 10-50 micro farad, 400VAC
Type | For lamp | Power | Operating current
(A) | Resistance
(Ω) | Tw
(ºC) | Δt
(ºC) | Power FactorcosΦ≤ | PF Cap.
(μF) |
Voltage
(V) | Freq.
(Hz) |
| NG35Z | HPS35 | 220 | 50 | 0.53 | 353 | 130 | 70 | 0.08 | 8 |
| NG50Z | HPS50 | 220 | 50 | 0.76 | 246 | 130 | 70 | 0.08 | 10 |
| NG70Z | HPS70 | 220 | 50 | 0.98 | 188 | 130 | 70 | 0.08 | 12 |
| NG100Z | HPS100 | 220 | 50 | 1.20 | 150 | 130 | 70 | 0.08 | 14 |
| NG150Z | HPS150 | 220 | 50 | 1.80 | 99 | 130 | 70 | 0.065 | 22 |
| NG250Z | HPS250 | 220 | 50 | 3.00 | 60 | 130 | 70 | 0.065 | 32 |
| NG400Z | HPS400 | 220 | 50 | 4.60 | 39 | 130 | 75 | 0.065 | 50 |
| NG600Z | HPS600 | 220 | 50 | 6.20 | 28 | 130 | 75 | 0.065 | 65 |
| NG1000Z | HPS1000 | 220 | 50 | 10.30 | 16.8 | 130 | 80 | 0.05 | 120 |
| M70Z | MH70 | 220 | 50 | 0.98 | 188 | 130 | 70 | 0.075 | 12 |
| M100Z | MH100 | 220 | 50 | 1.10 | 157 | 130 | 70 | 0.075 | 15 |
| M175Z | MH175 | 220 | 50 | 1.50 | 102 | 130 | 70 | 0.075 | 15 |
| M250Z | MH250 | 220 | 50 | 2.10 | 74 | 130 | 70 | 0.075 | 22 |
| M400Z | MH400 | 220 | 50 | 3.25 | 45 | 130 | 70 | 0.075 | 30 |
| M1000Z | MH1000 | 220 | 50 | 5.50 | | 130 | 80 | | 30 |
| M1000Z1 | HPI-1000 | 220 | 50 | 8.25 | 18.5 | 130 | 80 | 0.075 | 65 |
| G80Z | MV80 | 220 | 50 | 0.85 | 202 | 130 | 70 | | 8 |
| G125Z | MV125 | 220 | 50 | 1.25 | 134 | 130 | 70 | | 10 |
| G175Z | MV160 | 220 | 50 | 1.50 | 100 | 130 | 70 | | 12 |
| G250Z | MV250 | 220 | 50 | 2.15 | 71 | 130 | 70 | | 18 |
| G400Z | MV400 | 220 | 50 | 3.25 | 52 | 130 | 80 | | 25 |
LEALITE address lighting needs in a full range of environments-indoors (shops offices hotels factories) as well as outdoors (public places residential areas and sports areas). We also meet people needs on the road by providing safe lighting in traffic (street lighting)
LEALITE lamps offer more light per watt, longer life and feature a compact point source similar to incandescent, allowing good optical control. Main light bulbs include high pressure sodium lamp, metal halide lamp, mercury lamp. All lamps have CE certificated standard accessories: Ballast/ starter /fixed capacitor.
LEALITE steel poles are manufactured of Q235/Q345/A36 grade steel maintain a minimum wall thickness of 120 inch; And are circumferentially welded to the base. Aanchor bolts per ASTM A576nuts washers and threaded portion of bolts are hot DIP galvanized. Poles are finished in a premium polyester powder coat for superior weather-ability characteristics.
LEALITE roadway lights is ideal for roadways parking areas/ residential neighborhoods and bridge. Structures suitable for 2G vibration conditions. We deliver a range of innovative and reliable indoor and outdoor lighting and controls solutions specially designed to maximize performance energy efficiency and cost savings. The lighting business serves customers in the commercial industrial retail institutional residential utility and other markets.
LEALITE will support you fruitful products and satisfied service. Free samples can be sent for your evaluation
