| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty: |
3 Years |
| Color: |
Full Color |
| LED Chip: |
Epistar Fromtaiwan |
| Best Viewing Distance: |
7-150m |
| Frame Frequency: |
60Hz |
| Refresh Frequency: |
350Hz |
| Life Span: |
100,000hours |
| Mtbf: |
10000 Hours |
| Certificate Approved: |
CE,RoHS,SGS |
| IP Grade: |
IP 60 |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Pitch: |
7.62mm |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Density: |
17,222 dots / m² |
| Scanning Mode: |
1/8 Scan |
| System Operating Platform: |
WIN XP |
| Display Type: |
LED Video Display |
| Application: |
Shopping Guide |
| IP Rating: |
IP60 |
| Certification: |
SGS |
Product Description
P7.62 LED Display Strip
1. UL, CE&RoHS certificate
2. Excellent visual effect
3. Low power consumption
4. Life Span: 100, 000hrs
5. Warranty 5year
Features and Advantages
1. In order to ensure that images and tests are clear, vivid and consistent, all the chips for the entire RGB LED screens for outdoor screens within 100 square meters are at the same grade such as the same brightness and the same wavelength.
2. In order ensure screen background can become matt, completely absorb LED reflective light and eliminate shadow and ghosting, we adopt imported glue to varnish module surface, the glue thickness for each module is not more than 0.1mm, so the color is consistent and uniform.
3. To ensure product reliability and long life, we select the best chips for all outdoor display, red chips are from Hitachi brand, blue and green ones come from US CREE.
4. Easy to maintain and achieve single-pixel and single-lamp maintenance.
5. High quality at competitive prices. 6. Wide applied in stadiums, advertisemjent, banks, securities exchange, stations, entertainment, shopping malls, postal offices, schools, monitoring, restaurants, enterprises etc
| The technology parameter of P7.62 indoor |
| Item | P7.62 |
| 1 | Pixel pitch | 7.62mm |
| 2 | Size of unit board | 244mm X 122mm |
| 3 | Resolution of unit board | 32X 16 |
| 4 | Density of pixel | 17222dots/m2 |
| 5 | Pixel configuration | 1R1G1B |
| 6 | Red wavelength | 625±2nm |
| 7 | Green wavelength | 525±2nm |
| 8 | Blue wavelength | 470±2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | ≥8m |
| 11 | Horizontal viewing angle | 140° |
| 12 | Maximum power consumption | 600~1000W/m 2 |
| 13 | Brightness | 2000-5000cd /m 2 |
| 14 | Gray scale | 16bits per color |
| 15 | Color temperature | 6500k |
| 16 | Control method | Synchronization & Asynchronization |
| 17 | Driving method | 1/16 or 1/8 scanning |
| 18 | Frame frequency | 60Hz |
| 19 | Refresh frequency | 350Hz |
| 20 | Working voltage | AC220V/110V±10% |
| 21 | IP grade | IP20~IP65 |
| 22 | Working temperature | -20°C~80°C |
| 23 | MTBF | >10000 hours |
| 24 | Life span | >100,000 hours |
| 25 | Computer operation system | Win XP/Vista/ Win 2000/WIN7ect. |
| 26 | Video signal | RF, S-Video, RGB, RGBHV, YUV, YC.ect |
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
