| Prod Model: |
SZLF021 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Surveillance |
| Type: |
DSTN |
| Screen Size: |
≤17" |
Product Description
1. Outdoor-viewable touch screen
2. Available size: 3'11"
3. High resolution
4. High-speed response, stability, and never
Prduct Description
Display: 12.1" TFT LCD with resistive touch, Outdoor-viewable option
Display Resolution: 1024 x 768
Processor: AMD Mobile Sempron 1GHz
Operating Systems: Microsoft Windows XP Embedded / Windows XP Professional compliance
Storage:
Support up to 16GB flash memory module;
Support SSD (32 GB or 64GB );
Support HDD, 120 GB
Enclosure: Magnesium-aluminum alloy
Control Buttons: 1 mechanical switch power button, 1 power button, 9 programmable buttons
Input/ Output Ports: 1 COM port, 1 Mic-in, 1 Headphone out, 4 USB (2.0), Ethernet RJ45, 2 DC-in jack (AC-DC/ DC-DC), 1 PCMCIA slot, and 1 Express card slot
Network Interface:
Bluetooth Class 2,
Ethernet 10/100/1000 Base-T LAN,
Wireless 802.11a/b/g
|
4 wire Touch Screen |
|
Available size |
3”-11” |
|
Touch Activation Force |
20-150 g |
|
Thickness |
ITO film:0.188mm |
|
Operating voltage |
Less than 12v |
|
Operating current |
DC 50ma/5V |
|
X,Y resistance |
According to the size |
|
Insulation resistance |
≥20MΩ/25V(DC) |
|
Linearity: |
≤1.5% |
|
Response Time: |
<10ms |
|
Transparency: |
≥75% |
|
Surface Disposal: |
Anti Glare, Glare |
|
Operating Temperature: |
-20°C~+70°C,≤70%RH,noncondensing |
|
Storage Temperature: |
-30°C~+80°C,≤90%RH,noncondensing |
|
Humidity: |
<95% |
|
Surface Hardness: |
3H |
|
Pen Hitting Life: |
1millions times |
|
Pen Sliding Durability: |
100thousand times |
Shenzhen Lunfeng Engrave Board Co., Ltd. is a manufacturer engaged in the production, sale, and service of membrane switch, scutcheon, nameplate, acrylic nano lens, adhesive sticker, and hot press/injection molding thermosetting composite material (BMC/SMC).
Established in 1995, Shenzhen Lunfeng Engrave Board., Ltd. is located at Hengfeng Industrial Zone and Shajing Pioneer Industrial Estates, Baoan, Shenzhen, and covers more than 6000 square meters of modern plant, with large dust-free screen printing workshop, automatic screen printing machine, CNC carving machine, CNC cutting machine, 500T exclusive press and 218T injection molding machine, as well as punching, milling, grinding, drilling, production and testing equipment; Our company gatherers a group of experienced R&D Engineer and production workers. The production capacity of nameplate is more than 150 million annually.
Due to many years' experience, the quality of our products and service are widely praised by the industry field. Our company has maintained good cooperative relations with hundreds of companies in many countries and regions, such as Japan, Korea, Europe, America, Africa, Mid East and Southeast Asia. We have successfully provided products and services for well-known enterprises at home and abroad, such as SANYO, Haier, Midea, Mitsubishi.
Since founded, We have received various awards and honorary titles issued by the Government. Meanwhile, our company has passed ISO9001 International Management System Certification as early as 2001. Enterprise sticks to organize production\Insure Quality\strong quality inside\foster a good and healthy company image according to the ISO9001: 2008.
Primary Competitive Advantages:
1. Prompt Delivery
2. Quality Control (IQC, On Line Inspection, OQC, ISO9001: 2008 and 5S)
3. Reputation
4. Service
5. Small Orders Accepted
6. Superior R&D background (continuously new product development and current product improvement)
7. Customize Design / Production (OEM/ODM business, flexible designs for customers' special requirements)
