| Prod Model: |
UV series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Water Treatment Plant UV Sterilizer |
| Brand Name: |
Fillex |
| Condition: |
New |
| Material: |
Stainless Steel |
| Color: |
Sliver Gray |
| Delivery Time: |
30-45 Days After T/T Deposit or L/C |
| Payment Term: |
T/T or L/C |
| Warranty: |
1 Year |
| Style For Purifier: |
Portable |
| Operating Principle: |
Ultrafiltration |
| Certification: |
CE |
| Water Purification Efficacy: |
Straight Drink |
| Water Temperature: |
Cold, Warm & Hot |
| Descaling Function: |
Without Descaling Function |
Product Description
Large Capacity Water Treatment Plant UV Sterilizer for WaterSpecifications1. lowest price
2. good quality
3. high sterilization rate
4. maximum pressure:0.8mpa
5. lamp design life:9000-13000h
Small flow over current UV sterilizer parameters and selection table |
Model |
Flow rate |
Power |
Dimension |
Inlet/outlet |
FL-UV 05G |
0.5 GPM(0.1 T/H) |
8W |
250*48*65mm |
1/4'' |
FL-UV 01G |
1 GPM(0.2 T/H) |
10W |
295*60*80mm |
1/4'' |
FL-UV 02G |
2 GPM(0.5 T/H) |
14W |
370*60*80mm |
1/2'' |
FL-UV 04G |
4 GPM(1 T/H) |
17W |
450*73*110mm |
1/2'' |
FL-UV 06G |
6 GPM(1.3 T/H) |
23W |
520*73*110mm |
3/4'' |
FL-UV 08G |
8 GPM(1.8 T/H) |
28W |
650*73*110mm |
3/4'' |
FL-UV 12G |
12 GPM(2.7 T/H) |
40W |
950*73*110mm |
1'' |
Plastic card external fixation, electronic ballasts |
Medium flow over current UV sterilizer parameters and selection table |
Model |
Flow rate |
Power |
Dimension |
Inlet/outlet |
FL-UV 3T |
3 T/H |
40W*1 |
950*125*250mm |
1'' |
FL-UV 5T |
5 T/H |
40W*2 |
950*138*280mm |
1.2'' |
FL-UV 8T |
8 T/H |
40W*3 |
950*170*310mm |
1.5'' |
FL-UV 12T |
12 T/H |
40W*4 |
950*195*335mm |
2'' |
FL-UV 15T |
15 T/H |
40W*5 |
950*195*335mm |
2'' |
FL-UV 20T |
20 T/H |
80W*3 |
950*205*405mm |
2.5'' |
FL-UV 25T |
25 T/H |
80W*4 |
950*275*465mm |
2.5'' |
FL-UV 30T |
30 T/H |
120W*3 |
1250*275*545mm |
3'' |
FL-UV 40T |
40 T/H |
120W*4 |
1250*275*550mm |
3'' |
FL-UV 50T |
50 T/H |
120W*5 |
1250*275*550mm |
4'' |
Include stainless steel electronic cabinet, located in recessed below,
equipped with sight glasses, alongshore, time accumulated device,
tube running state light, etc
|
FAQ
Q1:Are you a trading company or a manufacturer?
A1:We have our own factory for many years,can give u best service .
Q2:What's your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 1 year guarantee . we will give u spare part free in 1 year,
Life long after service. Mean while, our engineers go more than 50 countries for debugging, with rich experience.
Q3:When can I get my machine after I paid?
A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives?
A4:We will send our engineer to your side as soon as you get all your machines ready , for testing
and teaching your technicians how to run the machines.
Q5.What's the delivery time?
A5.30-45 days after the T/T deposit or L/C.
Q6.What's min order quantity?
A6.1 unit
FILLEX is a professional filling, packaging, water treatment solution manufacturer from China with ISO9001: 2000 & CE certification who dedicated to manufacture kinds of filling & packaging equipment & water treatment system for beverage & food field.
Built in 2006, Fillex has 4000 square meters modern standard workshop & 40 professional workers, integrate the R&D department, manufacturing department, technical services department and marketing department together, provide the reliable filling system & water treatment system worldwide.
Fillex Manufacture & Provide below filling & treatment system
--PET Bottle, Glass Bottle, Cans, Cups Filling & Packaging Line(Still water, Carbonated soft drink, Juice, Alcohol, Oil etc)
--1-2 & 3-5 Gallon Jar Bottle Water Plant
--Beverage Filling Line Auxiliary Equipment(Carbonator, UHT Sterilizer, Turned-up Bottle Sterilizer, Spray Cooler&Bottle Warmer, Homogenizer, CIP System etc)
--Bottle, Kind of Container Labeling & Post Packing Solutions
--Water Treatment System(RO Pure Water Purifier, UF Mineral Water Purifier, Brackish & Seawater Desalination Plant, Water Softener)
