| Prod Model: |
STM-8-13 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
Laboratory Furnace |
| Type: |
Electric Holding Furnace |
| Fuel: |
Furnace |
Product Description
Laboratory furnace Technical data:
1. Furnace chamber material use mullite ceramic fiber materials, no powder pull off under high temperature, small heat capacity, and energy saving more than 50%..
2. Heating elements are SIC rod, which can undertake large loading, stable and longer service life.
3. Heating rate is 0-30ºC/min, can be set freely.
4. High precision temperature control, display accuracy:±1ºC, over temperature value is small, with the function of temperature compensation and temperature correction.
5. The temperature controller can set the program with 30 segments and can set the temperature curve.
6. With the function of leakage protection, safe and reliable.
7. With over-temperature alarm, when the temperature exceeds the set temperature, audible and visual alarm and stop heating.
8. Multiple safety protection design, good safety performance, long service life.
| Model | Volume | Chamber size W×L×H | Max.
temperature | Operating temp. | Voltage | Power | Heating element | Temp.
Precision |
| STM-8-13 | 8L | 200×300×120mm | 1300ºC | 1250ºC | 220V | 4KW | SIC rod | ±1ºC |
| STM-10-13 | 10L | 200×300×170mm | 1300ºC | 1250ºC | 220V | 5KW | SIC rod | ±1ºC |
| STM-15-13 | 15L | 200×400×180mm | 1300ºC | 1250ºC | 380V | 6KW | SIC rod | ±1ºC |
| STM-31-13 | 31L | 250×500×250mm | 1300ºC | 1250ºC | 380V | 10KW | SIC rod | ±1ºC |
| STM-45-13 | 45 L | 300×500×300mm | 1300ºC | 1250ºC | 380V | 12KW | SIC rod | ±1ºC |
