| Prod Model: |
SW001 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frequency: |
GSM850/900/1800/1900MHz |
| Chip: |
GSM/GPS:Mtk6261/Ubx7020 |
| GPRS: |
Class 12, TCP/IP Built in GSM Module |
| GPS Location Precision: |
10m(2D RM ) |
| GSM Location Precision: |
50-200m |
| Colors: |
Blue, Pink, Green |
| Anti-Dropped: |
Yes |
| Electronic Fence: |
Yes |
| Sos Button: |
Yes |
| Bluetooth Anti-Lost: |
Yes |
| Style: |
Watch |
Product Description
Intelligent children wear watches with GPS tracker
Model: GW001
1.Frequency: GSM850/900/1800/1900MHz
2.Chip:GSM/GPS:MTK6261/UBX7020
3.GPRS:Class 12,TCP/IP built in GSM MODULE
4.GPS location precision:10m(2D RM )
5.GSM location precision:50-200m
Colors:Blue,Pink,Green
Online tracking GPS watch phone
1.Anti-dropped
2.satellite and base station two models location keep safe for 24 hours
3.SOS button for helping
4.three models standby for battery save
5.remote monitor (Monitoring the sounds around the device )
6.Electronic fence
7.Bluetooth anti-lost
Personal gps tracker,
Worldwide use (GSM frequencies:850/900/1800/1900MHz)
GPS chip: MTK
24 hours real-time tracking
Both SMS tracking and web tracking availableInbuilt antenna
Remote Control,Geo fence
Inbuilt GPS Module
Supports fast dial button
One dail, two ways communication
Voice monitoring,Built-in speaker and microphone
Removable and rechargeable internal battery
Main functions Q50 GPS tracking smart watch
The dual control mode, mobile client or computer GPRS service platform
GPRS real-time positioning, tracking, monitoring;
Health plan step;
SOS emergency alarm;
Bluetooth anti lost;
Electronic fence;
Low battery alarm function
Take off the watch alarm
Remote shutdown
Basic Info |
| Model No. | GW001 |
| Products Type | GPS kids smart watch |
| Waterproof level | N/A |
| Screen Type | 0.96 or 0.66 inch OLED,support landscape and vertical screen |
| Battery | 400mAh |
| Standby time | 100hours |
| Talk time | 3hours |
| charging time | less than one hour |
| Button type | DAD MOM SOS ON/OFF(button color can be choosed) |
| Size | 31*52*12.5cm |
| Weight | 30-40g |
| Colors | Green,Blue,Red |
| Material | Environment protection 5-grade materials and resistance to shock |
| Hardware Info |
| Support system | Above Android 3.0,IOS 6.0 |
| Sim card slot | Support, micro SIM card |
| GSM GPRS | Support |
| OS | No |
| WIFI | YES(can choose) |
| GPS | Triple positioning system GPS+AGPS+LBS |
| remote software update | Support |
Remote debugging
maintenance | Support |
| Remote parameter set | Support |
| Low-power management | Support |
| Online enquiry for locaion | Support |
| History route playback | Support |
| SMS Enquiry for location | Support |
| Battery charging protection | Support |
| Sensor type | G-Sensor |
| Speaker | 8Ω/0.8W speaker x 1 |
| MIC | Support |
| Vibrate motor | Yes |
| Bluetooth | Bluetooth 3.0 |
| Buttons | one power on/off button,Refuse-call button,family number.volume button,SOS,Accept calls button |
| USB port | Micro 5 pin |
| Language | Multi-language |
| water proof | Living waterproof |
Chargeable connector
in watch | Yes, USB connector same as most phone |
Watch Configuration
through | APP on the mobile/ Internet |
| Watch strap | adjustable from 3-12 |
| Watch strap open/close | difficult for kids to open |
| SIM card insertion | put in at the back of watch |
| Mainboard Parametres |
| GSM main chip | MTK 6261, 364MHz |
| GSM | GSM 850/900/1800/1900 |
| GPS chip | MTK 3337 |
| GPRS | Class12 |
| GPS Signal | BD2, 1561.098MHz / L1,1575.42MHz C/A code |
| Number of channels for GPS | 22 channels |
| AGPS rapid positioning time | Cold Start 26s |
| GPS Sensitivity | tracking:-165dBm,capture:-148dBm |
| GPS Accuracy | 5-15m |
| LBS Accuracy | 100-1000M |
| Antenna | Built in GSM antenna and GPS antenna |
| Average standby current | <3mA |
| Average working current | About 55mA |
| Working temprature | -20~70ºC |
| Working humidity | 5% to 95% |
| Test and Certificate | CTA CCC CE |
| Mainboard stack size | 27 X 29 X 4.2mm |
| Input current | MAX1.5A |
| Input Votage | MAX 3.4-4.2V |
| Power | MAX 2W |
| Frequency | GSM880-915MHz;DCS1710-1785MHz;GSM925-960MHz;DCS1805-1880MHz |
|
|
|
| Function Detail |
| Functions | watch hands free call, two-way calling |
| SMS command, and voice message as well as SMS message |
| provide time on screen |
| push DAD or MOM button will call the stored number |
| push SOS, will sent an alert and SMS with time,date,GPS location to stored number |
| silent monitor, In case of an emergency, the parent can use their mobile to remotely switch |
| the watch to high sensitivity mode to listen the environment,the watch will not show any response |
| can stored extra 10 mobile numbers that can call the watch |
| control volume ring |
| use Google map to put location |
| Parent can control on/off button to avoid kids switching off the watch |
| can setup a time, like clock,and no-disturbing time |
| Electric fence, Parents can set safe range, once kidsgo away from the safe range, will sent alert to mobile |
| History route comprehensive monitor |
| perometer |
| sleep detector |
| Watch screen info. | Time |
| date |
| Battery |
| NWK status |
| Display MOM,DAD,Friends when ring |
| SMS message |
| Watch Package | Nice carton box |
| Manual book for watch and APK |
| Charger |
| USB Cable |
