Irmtouch Infrared Multi Touch Screen

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T

Send Inquiry

Showroom Product Company Profile

Prod Model:	IRMT
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Feature:	Touch Display
Touch Points:	2-64
Interface Type:	USB 2.0
Light Resistance:	Work Normally Under Sunlight
Driver:	Driver Free Under 20 Touch Points
Support System:	Win 7/8/XP, Android, Linux, Mac OS
Aspect Ratio:	16:9
Customized:	Customized
Screen Type:	Infrared
Screen Size:	12 Inch-400 Inch
Application:	Indoor~@~Computer~@~Advertising~@~Outdoor~@~Big-Sc

Product Description

As a leading infrared multi-touch screen manufacturer of China, IRMTouch Inc. Commits to providing flexible, stable and reliable IR multi-touch solutions to the touch industry. Based on its strong R&D team and core IR technology, IRMT has won several international patents. The product, IR multi-touch overlay (frame), may be conveniently assembled to LCD, LED, commercial kiosk, query machine, and interactive whiteboard to endow them with touch function. With the strength of oversized splicing multi-touch overlay and sunlight-proof solution, the IRMT product has been widely applied to various industries, such as multi-media, education, entertainment, exhibition, retail, and so on.

Advantage:
--Ultra-narrow border(21mm), large size, true multi-touch(up to 64 points)
--Support precise multi-touch: Up to 64 touch points(all are true points)
--Anti-ambient light ability: Work normally under sunligt without any influence
--Compound hybrid matrix, leading to a high fault-tolerant rate
--True multi-point with no ghost point, drift, nor blind area
--Sensitive operation and instant response
--support longitudinal and transverse screen installation
--Support touch area designation
--Support OS like Android(driver-free installation with true 10-points), Mac(6 points and gesture); Support protocols like TUIO, Flash and Windows.
--Support remote diagnose
--Solid hardware, supporting bulk shipment
--Low power comsuption without any extra power supply
--Do not need any Drive Installation, plug-and-play, even supper size 12*12m

Application
Interactive Media, Multi-Touch Table, Multi-Touch Wall, Interactive Display, Digital Signage, Kiosk, All-in-One, POS etc.

Shipment
1. All ordered units will be shipped out within 7 days via FedEx or DHL after order confirmation and payment.
2. To protect the units from potential damage during the delivery and save the logistics cost, all units will be delivered to customers in disassembled forms and without glass, we do recommend clients to order the tempered glass with 3mm-4mm thickness locally, it would be much convenient and cheap.
3. We could guarantee the lead time within 7 days for customized projects, while we couldn't promise the delivery time on international shipment due to customs clearing time in different countries.

Warranty
1.1 years parts and labor for customized projects
2. If the units are proved to be broken by the diagnose reports which contained in ZaagTech's driver, we would re-send new ones to clients for free in a month.
3. Warranty is valid except coverage for damage resulting from accident, liquid damage, disassembly, unauthorized service and unauthorized modifications.

Dimensions	Available Size	12-400 inch
Functional Parameters	Number of touch points	2 - 64
	Interpolation Resolution	32768x32768
	Linearity Error	1mm
	Authentication	CE,ROHS,FCC
	Response Time	6~16ms
	Protocol Supported	WIN7,TUIO,FLASH,and any customized protocols
	Operating System	WIN7/8,XP,Android,Linux,Mac OS,Vista
	Min touch Diameter	5mm
Optical Parameters	Luminousness	Max of 100%(no glass)
Environment Index	Temperature	Working:-20ºC~60ºC
	Temperature	Storage: -40ºC~85ºC
	Relative Humidity	Working: 10%~90%RH
	Relative Humidity	Storage: 10%~90%RH
	Light-proof Capacity	Resisting lights from all angles
Electric Parameters	Operating Voltage	+5VDC (range +4.75V~+5.25V)
	Power Supply Mode	USB power supply
	Power Consumption	1W~2.5W, varying according to different dimensions
	Interface	USB 2.0
Mechanical Properties	Touch Method	Any opaque object, such as finger, pen, glove etc.
	Touch Active	No need
	Safety	Different glasses can be selected at the request of safety grade
	Noise	No noise
	Surface	Oxidation treatment (black color)
Accessories	Standard	Double faced adhesive tape
	Alternative	Toughened glass & USB extension cord
	Warranty Period	One year
	Installation Method	surface mount

Welcome to visit our booth!

Shanghai International Digital Signage Show

Booth No. F75-F76
Date: 2014/9/25 - 27
Adress: No. 1099 Guozhan Roard, Pudong District, Shanghai
(SHANGHAI WORLD EXPO EXHIBITION & CONVENTION CENTER)

IRMTouch Inc. was a high-tech company which established in 2008. We specialized in Infrared Multi-Touch Devices. Making everyone have a joy experience of human-computer interaction and Change the human's style of reading, writing, playing is our philosophy.

We will continuously provide the most COST EFFECTIVE and STABLE touch devices for the market.

You can choose any points with our Multi-Touch screen. (2, 4, 6, 8, 10, 16, 32, 64 points)

As to now, we have become the leader in the touch industry. We have the most original R&D team, the patent named INFRARED MULTIPOINTS OF TOUCH SCREEN DEVICE AND MULTIPOINT LOCATING METHOD THEREOF authorized by United States PATENT AND TRADEMARK OFFICE in 2012 is the big revolution in Infrared Multi-Touch Industry, our products has got a break through in ANTI-AMBIENT LIGHT capability and truly Multi-Touch up to 64 points with high precision, linearity, fluency and smooth performance. Our team is growing and we have 12 R&D engineers which mostly have Doctor Degree.

IRMTouch is the leading touch screen manufacturer in China. We provide reliable, durable, and high performance touch solutions for Kiosk, ATM, POS, Gaming, Interactive whiteboard, Exhibition, military, Industrial control, machine or process controllers, point of sale devices, public information display, banking terminals and touch screen industry. The product, IR multi-touch overlay (frame), may be conveniently assembled to LCD, LED, commercial kiosk, query machine, and interactive whiteboard to endow them with touch function.

IRMTouch Inc. Commits to providing flexible, stable and reliable IR multi-touch products. We has expanded our business to the international market involves Korea, Japan, Spain and America.

IRMTouch Inc. Can provide all size of touch screen ranging from 32'' to 120'' that will be suitable for most of application in touch industry. And we can provide at most 64 true touch-points at the same time with the most outstanding algorithm.

As the leading touch screen manufacturer in China, we enforce the strictest quality control to meet the excellent performance and quality. Our products also hold safety certification including CE.

To be a high-tech company, we have the most advantaged technology and algorithm. We have a powerful R&D team with Doctor Degree. As a result, we have got many patents among which had been certified by United States Patent and Trademark Office.

Our products have the highest transparency and fluency. As the biggest revolution in the touch screen industry, IRMT has a high anti-glare character which determines we can perform excellently without any effect when you are in the sun.

IRMTouch Inc. Devotes to be International Company which offers strong support for promoting competitive ability and sustainable development. We invite you joining us! ! !
