| Prod Model: |
WS-AM1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
287mm X 287mm X 353mm |
| Weight: |
690g |
| Type: |
Voice Conferencing System |
| Video: |
Without Video |
| Communication: |
Wired |
Product Description
Conference Room Microphone System
Features
Universally compatible with most Internet communication applications such as Skype, Google Talk, Windows Live Messenger (MSN), Yahoo! Messenger, AOL, iChat and VoIP systems (i. e. Microsoft Office Communicator, Avaya solutions, etc
PC and Mac compatible with USB 1.1 / 2.0
Plug and Play, Free set immediately call
Compatible with real-time communication software, and VoIP software, all kinds of video conferencing software
16 kHz sampling sound quality, loud and clear sound, long talk reliable
Built-in high-end intelligent DSP high-speed full-duplex echo processing engine, two-way echo elimination
In addition, automatic filtering of background noise, not noise full-duplex transmission mode, even when listen to can still be speak at the same time, most close to the real communication
360-degree Omni-directional high sensitivity microphone, a radius of 5 meters are free to move around and make a call
A ural reception has no dead ends.
LED status lights, use different color ring on behalf of calls, in call, call mute state, all states at a glance
Switch the speaker headset, if visual occasion required, were suitable for multi-part or private conversation.
Conference System Platform.
| Model No. | WS-AM1 |
| Control Button | Volume control |
| USB Power switch |
| Microphone mute switch |
| LED Indicator | Agree Light indicates standby and talk mode |
| The red light mens silent mode |
| Sound Specifications | Sampling frequency:16KHz |
| Full-duplex at the same time talking |
| Echo Cancellation up to 60dB |
| Support AGC(Audio AGC) |
| Hardware Specifications | USB 2.0 Plug and Play Omni-directional microphone |
| 2W 4Ω speaker |
| USB Power |
| Microphone | Omni-directional |
| Sensitivity:-42 +/- 2dB(0dB=1V/Pa,1KHz) |
| 70 ~ 20,000 Hz |
| OS | PC and Mac with USB port |
| Instant messaging network software, including: Skype, Windows Live Messenger (MSN), Yahoo! Messenger, Google Talk, AOL, iChat, various of all kinds video meeting, instant messaging network software etc. |
| Broadband net play environment (ADSL or Cable Modem) |
| Working Enviroment | 0-60°,0-95% RH |
| Size | 287mm x 287mm x 353mm (L x W x H) |
| Weight | 680g |
