| Prod Model: |
led display(indoor p40)-03 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display Type: |
LED Video Display |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Scanning Mode: |
Static Scan |
| Certification: |
CE |
| Pixel Configuration: |
2R,1G,1B |
| Application: |
Shopping Guide |
| IP Rating: |
IP40 |
| System Operating Platform: |
WIN XP |
Product Description
Features:
1) Types: Indoor LED display screen, wireless control,
2) Colors: Full color
3) High definition and high brightness; Long durability and high reliability
4) Advance video control system and Super input system
5) Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting signal
6) Fit for various computer net
7) Standard connection socket
8) Easy installation, Low maintenance cost
9) Software for remote control of communication and scheduling
10) good heat emission capability
11) Customized design available
12) certification: CE and SGS.
13) Widely used in stage, concert, stadium, parties, bank, restaurant, station, shopping center, government, schools, and enterprise
| Pitch | 40 MM |
| Module size | 640 mm * 640mm |
| Pixel composing | 2R1G1B |
| Module Resolution(L*H) | 16 * 16 = 256 |
| Resolution ( Dots/ m2 ) | 625 |
| Brightness ( cd/ m2 ) | 1600 |
| The best view distance ( m ) | 60 |
| Max power consumption per module ( ≤W ) | 75 |
| AVG power consumption per module ( ≤W ) | 40 |
| Module weight (kg) | 12 |
| Scan mode | Static |
| View angle | H: 120 V:60 |
| Driver voltage(V) | 4.5---5.5 |
| Grade lever | 256 |
| Frame frequency | ≥60 ( frame/sec. ) |
| Control mode | Synchronization with PC |
| Life time | ≥100000 Hours |
| Bind spot rate | ≤0.0002 |
| 2Working voltage | AC220V±15 % 47 ~ 64HZ |
| Control distance(m) | <130 |
| Working temperature | -10°C ~ 50°C |
| Working humidity | 10 %~ 90 % RH |
Shenzhen DGX TECHNOLOGY Co., Ltd. is a high -tech enterprise which specialize in LED RD, design, production, assembly and so on, DGX locate in Bao'an district of Shenzhen China which is established in 2008 and has got 150 employees.
Our major products are full color LED outdoor/indoor display screen, LED tube light, LED indoor decorating lighting, scenery lighting and building lighting.
DGX 's culture soul is "morals, development and promise", all of our employees echnics management, quality and service are based on this culture soul.
DGX' s LED display and lighting products apply to night club, KTV, disco, theatre, building, plaza, square, TV station, all the lighting, entertainment, and advertisement field, we have got high reputation in these industry.
DGX apply Taiwan and CREE LED chip to ensure the vivid video effect and Technicolor, we have got many successful project, in every China province, Australia, EU, America, Africa and so on.
DGX is famous for high quality, fast response after service.
DGX develop all the business by international eyesight and developing policy to push LED industry in China and all the world, we are looking forward to wining the future with all global customers.
